I. Technical parameter
1. Raw material: Waste paper, wood pulp
2. Output paper style: Printing paper, copying paper and writing paper
3. Capacity: 35-40TD
4. Output paper weight: 30-60G/M2
5. Copper cylinder width: 2950mm
6. Net paper width: 2400mm
7. Drive way: Alternating current frequency conversion adjustable speed, section drive
8. Working speed: 80-120m/min
II. Main machine structure:
1. Cylinder part: 1500× 2950mm stainless steel cylinder 2sets, 450× 3000mm couch roll 2set, 450× 2850mm reverse roll 1set, pneumatic pressure device rubber shore hardness 38± 2.
2. Press part: Φ 600× 3100mm stone roll 1set, Φ 550× 3100mm rubber roll 1set, 450× 3100mm stone roll 3set, Φ 400× 3100mm rubber roll 3PCS., pneumatic pressure device rubber shore hardness 90± 2.
3. Dryer section: 2500× 2950mmdryer can 2 PCS, Φ 1500× 2950mmdryer can 14PCS, arrangement style: 186, 2ND dryer can section 450× 3100mm press roll 1 PCS, 550× 3100mm touch roll 1 PCS, pneumatic pressure device, rubber shore hardness 90± 2. There are dry felt device in the multi-cylinder section.
4. Calendaring and winding section: 3 roll calendar and cylinder winding machine
5. Drive and control section: Drive section with 500 speed reducer, alternating current, frequency conversion, digital sealed control system.
NO.
| name
| quantity(set)
|
| 1 | 2400mm paper making machine | 1 |
| 2 | dryer can exhaust hood | 1 |
| 3 | 850axial-flow ventilator 850 | 1 |
| 4 | 15type roots vacuum pulp | 1 |
| 5 | suction box | 6 |
| 6 | 2400mm winding machine | 1 |
| 7 | three roll calendar | 1 |
| 8 | 2400mm rewinding machine | 1 |
| 9 | pulp spray vat former | 2 |
| 10 | 10m3high consistency hydrapulper | 1 |
| 11 | up-flow pressure screen | 1 |
| 12 | high frequency vibration screen | 2 |
| 13 | 606type desander(10pcs) | 1 |
| 14 | IS250-200A desander pulp | 2 |
| 15 | ZSL1.2m2centrifugal screen | 1 |
| 16 | Φ 380mm double disc refiner | 3 |
| 17 | 14m3vat thicker | 1 |
| 18 | Φ 700mmthruster | 6 |
| 19 | 4 inch pulp pump | 10 |
| 20 | 6 inch pulp pump | 8 |
| 21 | frequency conversion controlling cabinet | 1 |
| 22 | air pump cabinet | 1 |
| 23 | work table | 1 |
Perfect service :
1.we can supply technical consulting and feasibility report according to client's current condition ;
2. We can make detail design of workshop and whole factory ;
3.we supply complete installation and test machine ;
4.we train client's engineer and worker for free ;
5.we supply spare part with best price ;
Company Information
Zhengzhou Guangmao machinery manufacturing co.,ltd has developed into a much more competitive company since establishment in 1982. Our complete paper production line sells well in international market, such as Russia,Indonesia,Uzbekistan,Tajikistan,Nigeria,Uganda,Pakistan,Egypt,Bhutan,Fiji,
Brazil,Paraguay,Syria,Libya etc. We also establish good strategic cooperation with local distributor. Mainlymanufactures all kinds of paper machines, toilet paper production line, Kraft paper production line, copy/writing paper production line. We have 4 paper machine producing workshops and more than 110 workers and more than 20 engineers. Our factory total area is 20,000 square meters. We sincerely welcome clients from all over the world visit our factory, any requirement, please contact via email, we will reply you as the first priority.We have passed CE, SGS, ISO quality system certification and all manufacture processes are conducted by the standard strictly.
FAQ
1.Why we choose your company, what could you do for me?
We have established for 10 years and have the stable production experience.
We use the best steel to guarantee the products' quality
Warranty:we make our machines one year warranty.
We will always give you heart to heart service
We always speak with facts and quality
2. How we visit your factory and what will be the procedure?
Our company located in Zhengzhou city,Henan province, if you take plane, it needs about 2 hours from Guangzhou city, 1.5hours from shanghai city and 1 hour from Beijing.we will pick you up from airport as well as the train station. We will take you to see our machine running in our Chinese clients' paper mill. Welcome you and your team to visit us at any time!
3. Could your engineer teach and train our worker and stay in our factory for long time?
Yes, we have very large engineer installation team,they can train and teach your worker to operate paper machine,but you should pay them salary.
4. How much water, electricity should I prepare for producing 1 ton finished paper?
(1) Clean water: 5M3
(2) Electricity: 250kw/h
5. Which kind of chemical I should prepare:
(1) Deinking agent
(2) Dispersing agent
(3) Bleaching agent
6. How about your company orders?
(1)One set of paper machine line or part is supported by us
(2) If we have urgent needs, we'll do it for you
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
