50-200mm PVC Waste Water Pipe Mold is mainly used for the UPVC, PVC sewage and waste water pipes extruding with the diameter from 50-200mm.
All pipe sizes as following:
50mm, 63mm, 75mm, 110mm, 160mm, 200mm
50-200mm PVC Double Pipe Mold includes the extrusion molds and caliberating sleeves.
Mold mateial: 37Cr Hardening and Chrome plate treatment
Mold heating: Stainless steel heating plates
Mold temperature control zones: 6zones
Temperature control method: PID automatic temperature controller
Caliberating sleeves: Made of brass and surface mirror polishing
|
Diameter |
Wall Thickness |
|
50mm |
2.0mm |
|
63mm |
2.3mm |
|
75mm |
2.5mm |
|
110mm |
3.2mm |
|
160mm |
4.0mm |
|
200mm |
4.5mm |
Suzhou New Chicheng Machinery Co., Ltd. is located in Jingfeng Town of beautiful Zhangjiagang City, which is a professional manufacturer researching, developing, manufacturing and selling plastic machines. In recenct years, the company keeps importing oversea technologies of plastic mixing and extrusion and it fabricated plastic extruder, wood&plastic profile production line, plate sheet production line. Of word top class as per international standard ISO9001: 2000. The company dominants local plastic machine market.
The company always stick to be duided by technology and keep improving internal management by spending a lot on innovation of equipment and importing technologies, hence, established an integrated production system consisting of work steps of csating, plating, assembling, commissioning and testing. The company leads the industry for its technical content, lenel of equip, size of scale and competition force.
