Main Features
The series include HWB100. They can be used to produce big hollow plastic products, such as gas tank, tool box and so on.
1) Clamping device: X-Axis construction, good rigidity, the space for mold is generous and mold changing is easy.
2) Die head: Adopt the principle "first in, first out" to keep even thickness of parison and high surface quality.
3) Operation is easy; Servicing is convenient, with a high degree of automation.
The HWB series is composed of clamping device, die head, extrusion system, hydraulic system, framework, pneumatic system, cooling system, electric control system and so on. There are robot, multifunctional bottom blowing device, parison controller, mechanical ejection, and hydraulic ejection that can be selected by customers.
HWB-100
Product max volume(L) 120
Diameter of screw(mm) 100
L/D 25
Plasticizing capability(kg/h) 175
Mold dimension(W*H)(mm) 1000*1000
Mold stroke(mm) 500-1200
Mold dimension(W*H)(mm) 800*1200
Mold thickness(mm) 510*650
System pressure(Mpa) 12
Clamping force(kn) 900
Accumulator volumes(L) 12
Max diameter of die head(mm) 420
Bottom blowing lifting stroke(mm) 250
Blow pin lifting stroke(mm) 150
Extrusion stroke(mm) 140-550
Framework lifting stroke(mm) 400
Extruder heating power(kw) 31
Die head heating power(kw) 22
Extruder motor power(kw) 45
Oil pump power(kw) 30
Servo motor power(kw) 4
General power(kw) 132
Average consumption power(kw) 58
General dimension(L*W*H)(M) 5.8*3.2*4.8
Weight(T) 15.2
Suzhou Huawang Machinery Co., Ltd. is a professional manufacturer of plastic extrusion blow molding machinery. Our company is located in Zhangjiagang, which is a well-know international garden city in Jiangsu Province, China. We enjoy a convenient location and we are near Shanghai, Suzhou, Wuxi and Changzhou.
Our company has a modern factory and offices. We have many skilled employees engaged in the manufacture of our blow molding machines and we pay particular attention to technical innovation and employee training. We strive to become an international enterprise in order to meet high quality requirements of the international market.
We produce 3 series of automatic blow molding machines: HWB single stations, double stations and fixed open-clamping machines. We can design machines according to the requirements of our customers.
Our ambition is endless, and we endeavor to provide you with the best service. We will be your reliable partner to create a prosperous future!
