Features of the Plastic Ram Extruder Machine:
1, Automatic control
2, Easy to operate
3, Low power consumption
4, Product size stability
5, Precise sintering
6, Environment-friendly and Energy-saving
Application:
PTFE RAM Screw Extruder products rod, and it has the best chemical corrosion resistance and the dielectric properties, not aging, not sticky, it also has the lowest friction coefficient. So the rod has a wide range of applications
About us:
JIANGSU SUNKOO MACHINE TECH CO.,LTD
Professional Experience: 10+ years only in the field of the PTFE Extruder
Manufacturing capacity: 50 sets / year.
Technology strength: Have a professional and experienced designer team to meet your any requirements.
Web: http://www.ptfe-machinery.com/
| Machine model | PFLB-20 |
| OD Size range | 4-20 mm |
| PTFE Products | Extruded Rod |
| Process | Vertical Type Ram Extruder M/c |
| Power KW(Main Motor+Heating) | 14 |
| Tolerance mm | 0-0.2mm |
| Length mm | Unlimited |
| Production Capacity Kg/H | 7-10+ |
| Electricity Consumption /H | 2 |
| Temperature Zone | 3-5 |
| Compressive Force(KN) | 50-250 |
| Weight of the Machine | 930 |
| Height of the Machine mm | 2150 |
| Floor Area of the Machine M2 | 3.5 |
| Warrenty for Parts | 1 Year |
| Machine Gurantee Period | 1 Year |
| Free Spares | 1 set |
| Floor Hole Dia mm | 400 |
| Frame inside size L*W | 800*800mm |
| Frame Outside size L*W | 850*850mm |
| Voltage/PH/Hz | 380V 50HZ 3 Phase |
We are leading of PTFE equipment in China with 10+ year experience. Expert manufacture of PTFE ROD Extruder, TUBE Extruder and SHEET Mould press machine and PTFE Mould, PTFE paste extruder for hoses. Machine has export to USA, Korea, India, Philippines, Indonesia, Malaysia etc.
PTFE Rod extruder: Produce OD 3mm - 150mm; 150mm - 500mm by mould press machine; OD tolerance: + - 0.02mm; From 150mm TO 600mm produce by 3000T vertical Mould press machine line.
PTFE Tube extruder: Produce OD 20mm - 500mm. NB300-500mm by mould press machine. Thickness of wall tolerance: + - 0.02mm; PTFE Vertical Mould Press machine produce 100mm to 600mm PTFE TUBE by 3000T power press machine.
PTFE Sheet Hydraulic press machine: To press thickness 3mm- 100mm with 1m*1m to 2.5M*2.5M size by 1000Ton to 8000T capacity;
PTFE paste extruder for Hoses OD 2mm to 50mm.
PTFE Film Skiving machine line make film from 0.2mm - 7mm thickness.
PTFE Gasket press machine depend on requried.
With fully technology support and process instruction to customers. Best after service after site commissioning.
