Plastic Ram Extruder Machine For PTFE Rod(Φ4-20mm)
This PTFE extruder is able to extrude rod which dia from 4mm to 20mm. The automatic
production line is controlled by computer, which is really easy to operate. Meanwhile,
the plastic extrusion machine is advance designed, high output, low energy consumption,
long-life, and also our professional engineer is available to offer overseas after sale service.
We can solve various problems to improve the equipment efficiency for you.
Ram extrusion machine for Teflon rod
The China vertical RAM Extruder is designed with 2 pressure plates, so the ream is affected
via a slid pressure plate. The China rod ram extruder is equipped with two hydraulic cylinders.
The main cylinder serves to move the ram; the additional cylinder serves for retracting the
mandrel. Base plate and dosing tray are water-cooled.
The PTFE powder is feed into the rotating hopper via an exact working powder dosing device,
controlled by a level indicator. By means of a rotating blade the powder is wiped uniformly into
the cavity of the mould.Range of diameter PTFE Extrusion 4 to 20 mm, Heating zones 4-6
zones.The complete electrical control is laterally fastened at rod ram extrusion. With a PC
touch screen panel all speeds and temperatures can be programmed. Electronics contain
the necessary automatic controllers for speeds and temperatures. Five temperature regulators
are contained in the plant, four for the extruding pipe and one automatic controller for a mandrel
heating element. The maximum output speed of PTFE extrusion depends on: physical property ,
like Specific Gravity and Elongation, outside of PTFE rod diameters and PTFE product heating
length.PTFE Equipment Warranty: according to our standard terms: 12months
Technical Specification:
PTFE Rod Extruder Dia 4mm-20mm
Technical Data
| Description Model No. | Machine model PFLB-20 |
| Plastic Extruder | PTFE |
| Power | 12 kw |
| Min - Max Dia | 4-20 mm |
| Tolerance | 0-0.2mm+ |
| Length | Unlimited |
| Production Per Hour | 7kg |
| Electricity Consumption Per hour | 2 kw |
| Weight of the Machine | 930 kg |
| High of the Machine | 2150 mm |
| Floor area of the Machine | 3.5 M2 |
| Warrenty for Parts | 1 Year |
| Machine Gurantee Period | 1 Year |
| Free Spares | 1 set |
| Deliver LT | 30 Days |
Features:
1, Automatic control
2, Easy to operate
3, Low power consumption
4, Product size stability
5, Precise sintering
6, Environment-friendly and Energy-saving
Application:
PTFE RAM Screw Extruder products rod, and it has the best chemical corrosion resistance and the dielectric properties, not aging, not sticky, it also has the lowest friction coefficient. So the rod has a wide range of applications
Company information
JIANGSU SUNKOO Machine TECH Factory is specialized in the Extrusion of PTFE (polytetrafluoroethylene)
based machine over 12 year. We manufacture PTFE Rod Ram Extruder, Tube Ram Extruder,
PTFE Moulding press machine and Paste Extruder, Film Skiving machine, and Sintering furnace.
Our organization is professionally managed by experts with rich experience and comprehensive
knowledge of the industry. Our core values are intrinsic to the way we work to strivetowards
leadership, trust and customer loyalty. PTFEmachine include PTFE rod extruder, PTFE tube
extruder, PTFE tube verticalextrusion machine, PTFE horizontal rod ram extruder,PTFE Sintering
Furnace, Skiving film machine and billet making machine underground with Isotatic water press
pump by membrane technology.
Our PTFE machine has been exported to USA, Russia, Korea, Saudi Arabia, India ,UAE etc.
Here would be a chance and opportunity to cooperate for mutual business with our technology
support. Welcome to visit our factory for business promotion.
www.ptfe-machinery.com
HOT TAGS:TEFLON PTFE ROD;TEFLON PTFE TUBE,TEFLON PTFE EXTRUSION
We are leading of PTFE equipment in China with 10+ year experience. Expert manufacture of PTFE ROD Extruder, TUBE Extruder and SHEET Mould press machine and PTFE Mould, PTFE paste extruder for hoses. Machine has export to USA, Korea, India, Philippines, Indonesia, Malaysia etc.
PTFE Rod extruder: Produce OD 3mm - 150mm; 150mm - 500mm by mould press machine; OD tolerance: + - 0.02mm; From 150mm TO 600mm produce by 3000T vertical Mould press machine line.
PTFE Tube extruder: Produce OD 20mm - 500mm. NB300-500mm by mould press machine. Thickness of wall tolerance: + - 0.02mm; PTFE Vertical Mould Press machine produce 100mm to 600mm PTFE TUBE by 3000T power press machine.
PTFE Sheet Hydraulic press machine: To press thickness 3mm- 100mm with 1m*1m to 2.5M*2.5M size by 1000Ton to 8000T capacity;
PTFE paste extruder for Hoses OD 2mm to 50mm.
PTFE Film Skiving machine line make film from 0.2mm - 7mm thickness.
PTFE Gasket press machine depend on requried.
With fully technology support and process instruction to customers. Best after service after site commissioning.
