APPLICATIONSMainly used for various chest ID badge, office board, architectural model, ruler, small metal and wooden mould making and embossing and so on.
STANDARD CONFIGURATION1. Integrally cast lathe bed, solid and stable, without distortion.
2. 3 axis transmission with imported ball screws ensures stable and smooth movement of the machine.
3. X and Y axis adopt synchronous belt and wheel transmission enable the machine work with high accuracy.
4. Application of the driver with high definition subdivision ensures fast speed and high accuracy.
5. High power spindle, brushless, water cooling, working vigorously with low noise, guarantees long time mass processing.
6. Humanized design enables easy disassembly of the machine for convenient transportation.
OPTIONS1. DSP off-line operation system.
2. Mist sprayer, water flume.
3. X,Y,Z axis HIWIN linear rail.
4. Rotary device.
5. HSD spindle.
TECHNIICAL PARAMETERS | Model | XZ1212 | XZ1215 | XZ1218 | XZ1312 |
| Working size(X*Y*Z) | 1200x1200x100mm | 1200x1500x100mm | 1200x1800x100mm | 1300x1200x100mm |
| 47.2x47.2x3.9inch | 47.2x59.1x3.9inch | 47.2x70.9x3.9inch | 51.2x47.2x3.9inch |
| Spindle Power | 1.5kw/2.2kw |
| Working Dictate | HPGL, Gcode |
| Operation System | NCStudio |
| Driving System | Stepper motor |
| Max Moving Speed | 8000mm/min |
| Max Engraving Speed | 4000mm/min |
| Reposition Accuracy | <0.04/300mm |
| Tool Diameter | φ3.175, φ6 |
| Spindle Speed | 6000mm-24000mm/min |
| Software | Type3/ucancam/Artcam |
Jinan Zenith CNC Equipment Co., Ltd., was founded in 2007, is a specialized manufacturer on advertisement equipments, due to the experiences of 9 years of research and manufacture in this field, we have produced "XZ" series CNC Routers for woodworking, advertisement stuff machining and mold processing, and laser equipments as well. "ZENITH" is our new brand for oversea market.
We make the high quality advanced machines, we are providing the best after-sale service in China. And we are also offering the most competitive price to all of the customers. "ZENITH" is known by more and more people. At present, our products have been exported to many countries and regions such as Czechic, England, Russia, Brazil, Paraguay, India, Australia, Thailand, Singapore, Malaysia, China Taiwan, and so on. We have enjoyed the mutual benefit and will move on, and we hope to establish a long term business relations with more and more oversea customers.
