Standard Configuration: | Option Parts: |
1)Working area: 1300mm*2500mm*200mm (X,Y,Z axis) 2) Solid steel frame construction 3) 3.0kw water cooling spindle. 4) Stepper Motors 6) HIWIN Linear Guide for maximum stiffness from Taiwan 7) DSP controller system 8) Automatic Tool Calibration 9) ArtCam software
Fuling Inverter 12) 220V 60HZ 13) Plywood case package | Oil mist cooling system (USD350) Delta AC Servo motors (USD3500) HSD Spindle |
The cnc router/cnc wood router Applicable Industry and materials:
1) Mould: wood,wax, wood, gypsum,foams,wax
2) Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and
windows.
3) The wood products: voice box, game cabinets, computer tables, table,instruments.
4) Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling
tracks, stairs, anti bate board, ABS
5) Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum
Plywood case package
Technical Data |
NO | Description | Parameter |
1 | X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
2 | X,Y,Z Repositioning Accuracy: | ±0.03mm/300mm |
3 | Max. Rapid Travel Rate | 80000mm/min |
4 | Max. Working Speed | 45000mm/min |
6 | Spindle Speed | 0-24000RPM |
7 | Command Language | G Code |
8 | Flash Memory | 512M |
9 | Collet | ER32 |
10 | X,Y Resolution | <0.03mm |
11 | Running Environment Temperature | 0 - 45 Centigrade |
12 | Relative Humidity | 30% - 75% |
13 | Packing Size | 3820*2200*2100mm |
14 | N.W. | 1600KG |
15 | G.W. | 1800KG |
Forsun is a leading global manufacturer of CNC routers, plasma arc cutting machines, and laser cutting machines. All the machines have been certified by CE. In manufacturing, the quality processes used are directly reflected in the excellent product that is delivered to your door. We have partnered with specific component manufacturers to deliver the best components for our machine systems. Our focus is on integrating advanced technology and value into systems that are highly productive, easy to use and built to last. Some of our strategic vendors include HSD Spindles, THK Bearing Systems, Siemens control system, YASKAWA servo, HIVIN linear guide and Eisler Reducer. As a machine builder, the exacting manufacturing processes we have created ensure that even custom systems can be engineered, manufactured and delivered with the shortest manufacturing lead times in the industry. We are near to you physically, and only a phone call or email away electronically for machinery, software and consumable sales as well as after sales support. Count on Forsun to work with you in your machine decision process, to build you an excellent quality CNC router that will work for years, and to continue to support you and your machine decision for years to come. We strive toward exemplary customer satisfaction, employee career fulfillment and corporate citizenship. Success in these areas, we believe, will yield long-term benefits for the Forsun brand, Forsun employees and our partners.
