(I). Technical parameter:
Raw material: Waste paper and pure wood pulp
Output paper: Kraft paper, corrugated paper
Weight: 130-300g/m2;
Capacity: 20-25T/D
Net paper width: 2100mm
Wire width: 2450mm
Rail gauge: 2900mm
Drive way: Speed adjustment in AC frequency &processing transmission
Work speed: 80-120m/min
(II). Main frame of equipments:
1. Cylinder part: 1250mmx 2450mm x 2900mm stainless steel plate style cylinder mould 3 pcs, 450mm x 2450mm x 2900mm couch roll 3 pcs, 450mm X 2450mm x 2900mm reverse roll 1 pc, rubber hardness HSD 80° ± 2,
2. Press part: 600mmx 2450mm x 2900mm rubber roll 2pcs, rubber hardness HSD 92° ± 2, 650mm x 2450mm x 2900mm natural marble stone roll 2 pcs, pneumatic loaded device.
3. Dryer part: 1500mm x 2450mm x 2900mm alloy dryer can 6 pcs, it is equipped with dry mesh device.
4. Calendar part: Three rolls calender1set, bottom roll 400mm x 2450mm x 2900mm, Middle roll 250mm x 2450mm x 2900mm, Rearward roll: 300mm × 2450mm x 2900mm 5. Reeling part: 900mm reeling machine
|
No |
Item |
Power
(kw) |
Grade |
Qty
(set) |
|
1 |
2100mm multi-dryer can multi-cylinder mould paper machine |
|
|
1 |
|
First main Press part |
30 |
4 |
1 |
|
Secondary main Press part |
22 |
4 |
1 |
|
Cylinder group |
11 |
4 |
1 |
|
2 |
Exhaust hood of dryer group |
|
|
1 |
|
3 |
Axial flow fan |
7.5 |
4 |
1 |
|
4 |
Style 15 roots pump |
15 |
4 |
2 |
|
5 |
Suction box |
|
|
5 |
|
6 |
2100mm calender machine |
11 |
4 |
1 |
|
7 |
2100mm reeling machine |
7.5 |
4 |
1 |
|
8 |
AC frequency controller |
|
|
1 |
|
9 |
Working table |
|
|
1 |
|
10 |
Air pump |
|
|
1 |
Our company has over 420 employees. There are five factories in China with the total area of 20, 000m2, it has passed the ISO14001 international authentication
Our products include paper making machines, parts and paper processing machines such as kraft paper machine, tissue paper machine, cultural paper machine, fiber separator, hydrapulper, rewinder, napkin folder, tisue slitter and ao on. They have been exported to more than 8countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying in perfect & advanced technology, sincere service and inexpensive products with high quality, we have won the recognition of international market and clients
Why choose us
Our company gathers a technique team of engineers and experts with over 30 years' experience which helps us be a professionall on all kinds of paper making machines and make us competitive on the market. We focus on quality and customers' need and improve our technology and service continually. We believe our devotion to work will help us to achieve global leadership in providing first-class products and superior quality services to customers around the world
Our advantages
Technical advantage
1. Experiences producing team
2. Advanced technological strength
Product advantage
1. Through the international authentication
2. Same material with most preferential price
3. A lot of varieties for the customer to choose
Service advantages
1. Technical consultation
2. Project evaluation
3. Detailed design of factory
4. Installation and test the whole production line
5. Training engineers and workers
6. Supplying spare parts for long time
