Main Index
| Description | Max. inlet | Min. outlet | Motor power | Max. speed | Noise |
| DL1000 | Φ16mm | Φ8.0mm | 110kw | 0.5m/s | 80-83dBA |
| DL900 | Φ14mm | Φ6.0mm | 90kw | 0.5m/s | 80-83dBA |
| DL700 | Φ10mm | Φ4.0mm | 75kw | 1m/s | 80-83dBA |
| DL600 | Φ8.0mm | Φ3.2mm | 55kw | 1m/s | 80-83dBA |
| DL550 | Φ6.5mm | Φ2.5mm | 45kw | 1m/s | 80-83dBA |
| DL450 | Φ5.0mm | Φ1.5mm | 30kw | 1.5m/s | 80-83dBA |
| DL350 | Φ3.5mm | Φ1.0mm | 22kw | 2m/s | 80-83dBA |
Usage:
Mainly used in the field of wire rope making, standard industry. Which is suitable for low, medium, and high carbon steel wire.
Main index:
1. Adopt double enveloping worm gear reducer or reducer hard-toothed surface.
2. With a guide rail, handbarrow, convenient replacement of flower frame.
3. Equip bilayers of different diameter drum, large technical range
Installation Requirement
| Pos. | Item acceptance | Requirement |
| 1 | position and height of the equipment | adjust the level, height tolerance between the inlet and outlet no more tham 2mm |
| 2 | Fixture of the equipment | Fixed solid, no violent dithering phenomenon during operation |
| 3 | Water tube, air tube, oil tube | No leaking, no air leakage, no oil leakage |
| 4 |
No-load test | 1. Running normally, can not have the phenomenon such as jam, violent vibration and sound
2. Each drum speed matching
3. The action of the switch button is normal |
| 5 | Equipment load test | Equipment operation is normal, qualified product quality, equipment performance is stable |
Wire drawing machine is customized products, we will precise calculate according to the customer's requirements, providing customers with the most suitable products, the perfect on-site installation and after-sales service.
Our company will provide the whole machine quality assurance for one year, belt and quik-wear parts warranty for 3 to 6 months.
Jiangyin Hengyi Electromechanical Co., Ltd is a high-tech manufactory which is specialized in wire drawing machine, lighting material and precision alloy material. The main products are various wire drawing machine, dumet wire, nickel-coated steel wire, soft magnetic alloy, expansion alloy, thermostat bimetallic strip, ect...Also our company has obtained the GE Approval and CSA Approval.
Our company has gained good reputation in domestic and overseas market with superior quality, reasonable price and perfect afer-sales service. So far, we are obedient to the principle of Create Value for Customers. If you are interested in our products, please feel free to contact us for more information.
For more information, you could browse our website www.jyhengyi.cn
