I. Technical parameter:
1. Raw material: 100%recycle paper
2. Output paper: Tissue paper;
3. Paper weight: 14-40G/M2;
4. Net paper width: 2800mm;
5. Width of cylinder mould: 3300mm;
6. Capacity: 11-12ton per day;
7. Working speed: 150-200m/min;
8. Rail gauge: 3900mm;
9. Drive: Alternating current, frequency converter, speed control, section drive;
II. Structure and characteristics:
1. Cylinder section: One stainless-steel plate type cylinder mould(Φ 1800mm× 3300mm). One Sealed pressure cylinder vat. One couch roll (Φ 500mm× 3300mm), coated by rubber, rubber hardness HS-38C± 2.
2. Dryer section: One dryer can (Φ 3000mm× 3300mm), one touch roll(Φ 600mm× 3300mm), pneumatic loading device. Coated by rubber, Rubber hardness HS-90C± 2, dryer can equipped with one set of Double layer exhaust hood.
3. Winding section: One sweat cylinder (Φ 1000mm× 3300mm), winding paper on sweat cylinder.
4. Rewinding and cutting section: Equipped with 2880mm rewinding & perforating machine,
5. Drive & Control section: Alternating current, frequency converter, speed control, section drive;
| NO. | Item | Qty(set) |
| 1 | 2880mm high speed tissue paper machine | 1 |
| 2 | exhaust hood of dryer can(double layer) | 1 |
| 3 | Φ 850mm axial-flow ventilator | 1 |
| 4 | Sealed pressure cylinder vat | 1 |
| 5 | 15 type roots vacuum pump | 1 |
| 6 | Suction box | 2 |
| 7 | 8m3 High consistency hydrapulper | 1 |
| 8 | 2m2High frequency vibrating screen | 1 |
| 9 | 35 m3 bleacher | 4 |
| 10 | Φ 450mm double disc refiner | 4 |
| 11 | Φ 700mm thruster | 6 |
| 12 | CX1.6m2centrifugal screen | 1 |
| 13 | 606 desander (12pcs) | 2 group |
| 14 | 4 inch pulp pump | 4 |
| 15 | 6 inch pulp pump | 6 |
| 16 | 2880mm rewinding & perforating machine | 1 |
| 17 | CV-450Cutting machine | 1 |
| 18 | Air Pump cabinet | 1 |
| 19 | Frequency control cabinet | 1 |
| 20 | 2T boiler(burn coal) | 1 |
IV. All necessary electric motor
| NO. | Item | power(kw) | Grade | Qty(set) |
| 1 | 1st dryer can section | 45 | 4 | 1 |
| 2 | Sweat cylinder section | 7.5 | 4 | 1 |
| 3 | Φ 850m maxial-flow ventilator | 5.5 | 4 | 1 |
| 4 | 15type roots Vacuum pump | 15 | 4 | 1 |
| 5 | 8m3 High consistency hydrapulper | 90 | 6 | 1 |
| 6 | 2m2 High frequency vibrating screen | 4 | 4 | 1 |
| 7 | 35 m3 bleacher | 4 | 4 | 4 |
| 8 | Φ 450mm double disc refiner | 75 | 6 | 4 |
| 9 | Φ 700mm thruster | 11 | 6 | 6 |
| 10 | CX1.6 m2centrifugal screen | 37 | 4 | 1 |
| 11 | 4 inch pulp pump | 4 | 4 | 4 |
| 12 | 6 inch pulp pump | 11 | 4 | 6 |
| 13 | 2880mm rewinding & perforating machine | 5.5 | Speed control | 1 |
| 14 | CV-450Cutting machine | 3 | 4 | 1 |
| 15 | Air Pump | 5.5 | 2 | 1 |
| 16 | 2T boiler(burn coal) | 7.5 | 4 | 1 |
| 4 | 4 | 1 |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
