Hot Induction PLC Hydraulic Welded Rolling Big Bending Radius Bending Machine
Shean patent product Hot Induction PLC Hydraulic Welded Rolling Big Bending Radius Bending Machineshows a new era in Pipe fittings industries.
Brief introduction about Hot Induction PLC Hydraulic Welded Rolling Big Bending Radius Bending Machine:
1. Bending material: Carbon seamless steel, 20G, A106B, A106C
Welded pipe: 235B, 345B, X42, X52, X60, X70
Alloy steel: 335P12, P22, P91, 12Cr1MoVG, WB36
With PLC control system, bender thickness reducing 5-10%
Oval: 5%
Waver: Hot 2%
Plain L=500 3%
Bending angel tolerance +/-0.5 degree
3. Integrated hydraulic system
4. Infrared radiation thermometer, temperature control automatic tracking and obvious show.
5. PLC Control system working element theory:
5.1 Keep machine strength, especially clamp head parts, use strong complete casting way to keep
Bending intensity facing big force when pushing
5.2 Install magnetism ruler and sensor organ to transmit machine force, speed, temperature to PLC Screen.
5.3 PLC Screen has English version and Chinese version.
5.4 End user need to put element informations to PLC system, like: Bender
Size, thickness, radius, pushing angle, raw mother pipe material etc
6. Features of machine
Slide rail design to make support board running more smooth
Slope steel clamp is a special technology in Hot Induction PLC bending machine. With such design, clamp tightening is more strong, more pushing forward more tight at end.
|
Serial number |
Max diameter |
Max thickness |
Stroke of cylinder |
Quantity of cylinder |
Max thrust |
|
(mm) |
(mm) |
(mm) |
(piece) |
(t) |
|
|
|
|
|
|
|
1 |
1420 |
20 |
6500 |
4 |
670 |
|
2 |
1220 |
20 |
6500 |
4 |
600 |
|
3 |
1020 |
20 |
6500 |
4 |
500 |
|
4 |
820 |
20 |
6500 |
4 |
400 |
|
5 |
720 |
20 |
6500 |
4 |
320 |
|
6 |
630 |
20 |
6500 |
2 |
300 |
|
7 |
530 |
14 |
6500 |
2 |
160 |
|
8 |
426 |
14 |
6500 |
2 |
130 |
|
9 |
325 |
14 |
6500 |
2 |
84 |
|
10 |
219 |
12 |
6500 |
2 |
65 |
Shean (Cangzhou) Corp Ltd registed in 2011, production line started in 1994. Has technician 10 persons, workers 50 persons, sale clerk 12 persons. For years, Shean helps heavy industrial enterprises gain huge profit domestic and abroad. Shean started foreign business since 2008 as while as good domestic sales. In 2014, Shean will creat another workshop as showroom of various machines running and head office will move to Cangzhou City with 900 square meters.
Our main scope for making and sells are: Induction pipe bending machine, Elbow forming machine, Tee machine, Hydraulic press, Pipe fittings, elbows, tee. "good products and complete after sale service " is our core principle.
Product covers all over the world, like USA, England, Russia, Turkey, India, Poland etc.
Welcome you visit Shean (Cangzhou) Corp Ltd.
