Model NO.:
DIN 1.2316/S136/3Cr17NiMnMo
Type: Steel Plate
Technique: Hot Rolled
Standard: ASTM, AISI, GB, JIS, DIN
Surface Treatment: Black Surface
Application: Plastic Mould Steel Plate
Grade: DIN 1.2316/S136/3cr17nimnmo
Surface: Black Surface
Place of Origin: China
Certification: ISO9001: 2008; SGS Test; Mtc
Condition: Hot Rolled, Pre-Harden
Hardness: 32~36HRC
Delivery Time: 7~15 Days
Export Markets: Global
Additional Info.
High Quality
Various Type
Competitive price
On time delivery
Product Description
DIN 1.2316/S136 Steel Plate
DIN 1.2316/S136 Steel Plate / Mould Steel Plate / Steel Plate Bar / Mould Steel Plate Bar / Plastic Steel Plate / Plastic Mould Steel Plate / Mould Steel
DIN 1.2316/S136/3Cr17NiMnMo Steel Plate/Mould Steel Plate/Plastic Steel Plate
1. Hot rolled condition, Pre-harden, black surface
2. Hardness: 32~36HRC
3. Hot rolled technology: EAF+LF+VD
4. Heat treatment quench: 1020-1050° C, oil cooling or quenching liquid colling, hardnessHRC≥ 45
Backfire: Temperture(° C): 100 200 300 400 500 600
Hardness(HRC): 49 47 46 46 47 32
5. Production leadtime: 7~15 days
6. Ultrasonic test standards: Sep1921-84, Gr. 3, Class C/C or D/D
7. Applications: Used for making the corrosion resistance and wear resistance of high quaity plastic mould, transport plastic mould, like PVC and CD mould
Competitive Advantage:
1. Pure & Precision mirror polishing
2. Highly quality of corrosion resistance
3. Convenient heat treatment for quenched&tempered steel, with out deformed
4. Easy for welding
5. Competitive price
6. Fast production leadtime
7. All the material are inspected with 3 times to meet the highly standards
8. Stable quality to be guarantee
|
C |
Si |
Mn |
P |
S |
Cr |
|
S136 |
0.34-0.42 |
0.6-1.3 |
0.2-0.7 |
≤0.03 |
≤0.03 |
13.0-14.5 |
|
1.2316 |
0.34-0.40 |
0.6-1.3 |
≤1.0 |
≤0.03 |
≤0.03 |
16.0-17.5 |
