HXE-14DT Fine Wire Drawing Machine with Annealing
Main technical parameter
Usage single | bare copper wire drawing and annealing |
Inlet size | 0.8mm-1.6mm |
Outlet size | 0.25mm-0.6mm |
Machine speed/max | 2000m/min |
Die number | 14 |
Wire drawing mode | standing-mode and 4axes |
Drive | by dual inverters control |
Main motor | 11KW AC 3 phase motor |
Spooler motor | 3.7KW AC 3 phase motor |
Annealing voltage | DC50V/max |
Annealing current | DC300A/max |
Annealing power | 16KVA |
Annealing method | D.C three-section annealer |
Quantity of steam | 8kg/h |
Capacity of compressed air | 0.4-0.6Mpa,15L/min |
Demand Water quantity for annealing and coolant | 150L/min |
Machine frame | welded by steel plate |
Transmission | flat straps |
Capstan | ceramic coated |
Lubricating system | Spray |
Bobbin size | 300mm, |
Bobbin loading &unloading type | shaft type |
Traversing unit | 110W synchro motor, width: 270mm/max |
Brake | 20KG-M magnetic brake |
Machine weight | 3000KG |
Suzhou Hengxie Machinery Co., Ltd. Locates in Yinghu Industrial Zone, Wangting town, Suzhou Hli-New District, near to G312 with a conveninet transportation and nice environment. It is a professional company which specializes in electronic cable, electromagnetic cable, electrical wire eat. It is at a leading position in this line because of the topping managing talent and advanced technics.
Hengxie has invested RMB ten Millons to introduce the Germany equipments and technics and developed the cable producing line by itself. This ensures the quality stable and capability superior. Hengxie has successfully set up a superior enterprise mode.
With the mange concept"Stable Quality, Mutual Development" Hengxie warmly welcome alll the friends to grant the changefor sincere cooperation and win the mutual benifit in the future.
