Specifications:
1).High Automatization
2).High Intelligence
3).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
4).High Speed
5).No Contamination:Closed production zone, good self-lubrication system avoid contamination.
6).Low Cost:Low consumption of electricity, air and water.
7).High Transparency:Easy maintenance, absolute safely, visual inspection, low noise.
For more information, please feel free to contact us.
Samples:
Max. product volume |
L |
1200 |
1600 |
2000 |
Station |
Pc/h |
single |
single |
Single |
Dry cycle |
mm |
30 |
30 |
30 |
Screw Diameter |
L/D |
120*2 |
120*2 |
120*2 |
Screw L/D radio |
KW |
32 |
32 |
32 |
Screw heating power |
KW |
23.6*2 |
23.6*2 |
23.6*2 |
NO. of heating zone(Screw) |
ZONE |
6*2 |
6*2 |
6*2 |
Output of HMWHDPE |
Kg/h |
350*2 |
350*2 |
350*2 |
Hydraulic pump driving power |
KW |
11+15=26 |
11+15=26 |
11+15=26 |
Clamping force |
KN |
2000 |
2000 |
2000 |
Platen distance |
mm |
400~2800 |
400~2000 |
400~2000 |
Max. size of mold |
W*H/mm |
1600*1800 |
1600*1800 |
1600*2000 |
Capacity of Accumulator head |
L |
65 |
70 |
100 |
Max. die diameter |
MM |
750 |
1400*120 |
1500*120 |
Die heating power |
KW |
90 |
90 |
95 |
No. of heating zone |
Zone |
24 |
24 |
30 |
Blowing pressure |
Mpa |
1.0 |
1.0 |
1.0 |
Air consumption |
M3/MIN |
5 |
5 |
5 |
Cooling water pressure |
Mpa |
0.4 |
0.4 |
0.4 |
Water consumption |
L/MIN |
350 |
350 |
350 |
Size of machine |
L*W*H/m |
11.5*9*6.9 |
11.5*9*6.9 |
11.5*9*7.2 |
Weight of machine |
TON |
70~75 |
70~75 |
70~75 |
FMI (Future Material Inc. ) offers turn-key extrusion system of plastic composite including single-screw and twin-screw extruder, high output and precision extrusion dies by adopting unique patented, proprietary technology and advanced computer-aided engineering (CAE).
We provide research & development, manufacturing and sales of the extruders applied for other raw materials, industrial application software, and we work closely with customers and provide technical consultation and service for plastic material, equipment and extrusion process to reduce costs from every aspect in technology, system, investment and operation.
We are confident that FMI is your best choice.
