Pet Preform Injection Moulding Machine (LSF208)

Pet Preform Injection Moulding Machine (LSF208)
Price: US $ 31000/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
We are professional manufacturer of Pet Preform Injection Moulding Machine, clamping from 600 to 32000KN, weight from 68g to 40570g.

Our machines are known for the features like durability & sturdy construction.

We are manufacturer of

Have ordinary, servo motor energy saving, variable pump and high speed series.

Different model for different production requirements, welcome contact us for more details and professional services.

Some of the important features:
Clamping system: Faster response, steable and high rigidity
Injection system: Accurate and flexible, lower rejection rate
Control system: Computer and simple operation, molding data memory system
Power system: Energy saving, high efficient and precise
Metal parts: The thickness of our frame, metal plate and wallboard are thicker than other company.

Other Information
Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production
Visiable lubrication system: On time clean, avoid cast steel parts abrasion and broken.
Oil treasure: Filter of hydraulic oil, good for pump and valves
Long working life: Imported spare parts and updated version
Aftersales service: Professional & timely
Delivery time: 30-60 days
Port of dispatch: Shanghai




INJECTION UNIT
  Unit LSF-208
A B C
Screw Diameter Mm 45 50 55
Screw L/D Ratio L/D 22.2 20 18.2
Short Size Cm3 381 471 569
Injection weight G 347 428 518
oz 12.2 15.1 18.2
Injection Rate g/s 170 210 254
Plasticizing capacity g/s 19 23.2 28.7
Injection Pressure Mpa 229 186 154
Screw Speed Rpm 0-190
Injection Sroke mm 240




CLAMPING UNIT
Clamp Force KN 2080
Space Between Tie Bars mm 510*510
Toggle Stroke mm 500
Max. Mold Height mm 530
Min. Mold Height mm 200
Ejector Stroke mm 150
Ejector Tonnage KN 62
Ejector Number P 5


OTHERS
Max. pump Pressure Mpa 16
Pump motor powder Kw 18.5
Heater Power Kw 14.25
Machine Dimension(L*W*H) M 5.3*1.4*1.95
Machine Weight T 6.9
Oil Tank Capacity L 380
Hopper Volume Kg 50
Prod Model: LSF208
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Preform Injection
Automation: Automatic
Structure: Horizontal
Computerized: Computerized
Plastic Type: Thermoplastic
Changzhou Longsheng Machinery Co., Ltd locates in Zhonglou Scientech Industry Park of Changzhou, mainly produces and sells Plastic Injection Molding Machine, with high technology and reliable quality, our products are selling all over the world. We compare the price with the same quality, while compare quality with the same price, compare the service with the same quality and price, we regard it as our management tenet. We always integrate the optimized design associated with manufacture and good sales service together. We adopt 24hours-networking for sales service, all lifecycle services for products, smile is our characteristc service.

Ways to success, start from Longsheng. Longsheng Possesses solid strength, devoted to create a brand name ---Longsheng Machinery Series. The Clamp Force of our machines range from 600KN to 16800KN, Shot Weight range from 63G to 10000g, Plastic Injection Molding Machine is widely applied in the areas of automobile, mechanical, chemical, electrical, daily supplies, toys, etc.

With good quality, professional service and sincere credit, Longsheng will go along with new and old clients, to realize the complementary of each other's advantages, resource sharing and mutual benefit. Try to create a prosperous future with our customers as we always do.

Innovation is the sole of development for a company. The Sea Accepts All Things, Deriving More Things. The development of Longsheng is course of creative and exceed itself all the time. Study is the vital force of the enterprise, the Longsheng advocate study, and offer all-sided training to improve its staff. Devoted to everything on hand is the management concept of Longsheng, owning concentration and persistence, the enterprise could progress, the staff can improve themselves.
