PLASTIC MOLD
PET Hot runner plastic mold employs PID controlling system which features automatic compensation and automatic protection, and contributes to the prolongation of lifetime of electric heater;
The precision of temperature controlling falling within 1º C, which ensures to avoid plastic in the hot runner being burnt, resulting in a yield of up to 99% and more;
Ultra nozzles are designed to be maintenance-friendly. Nozzle tip inserts, heaters, tip insulator, and thermocouples are easily accessible and can be replaced and maintain.
Our offer PET preform mould was hot runner mould that not need manually cutting the injection gate after injection. Plastic mold was supplied with mold temperature controller. Each cavity temperature can be controlled by it.
Pneumatic Pin Valve Gate Design,
Insulation gasket was imported from DUPONT brand, USA.
Valve needle was imported from Japan
The plastic mold frame material is P20
The plastic mold inside cavity&core material is S136 stainless steel
The plastic preform mold's heater coils is Germany brand hotset
The graphite material copper
For our PET plastic mold with hot runner system
Heater nozzle with valve gate system (copy husky)
Cavity: Steel Germany HRC 46-50
Core: Steel Germany HRC 46-50
Neck: Steel Germany HRC 45-48
Mold life: Aprox 4millions shots
Zhangjiagang Great Machinery Co., Ltd. is located in the new river port city-Zhangjiagang, which is about two hours by car from Shanghai.
Our company is specialized in designing and producing Blow molding machine, PET bottle blowing machine, Injection molding machine, Injection blow molding machine, Plastic mould and Plastic products.
For about ten years study and endeavor, we have great development in plastic industry field. Our machines and moulds have been exported to many countries in Southeast Asia, Middle East, Middle Asia, South Africa, South America, Europe, Canada and Russia. All of our clients give high reputations for our machines and services.
Our main products like:
0.2L-220L Blow molding machine
60T-4000T injection molding machine
0.2L-5L Fully-automatic pet bottle blowing machine
0.2L-20L Semi-automatic blow moulding machine series
0.1L -0.5L injection blow molding machine
PET preform mold from 1 up to 72cavities
PET preform and cap for mineral water & carbonated beverage
Look forward to your visit and cooperation!
