ZHTF-1500K Spiral Tubeformer
I Description of ZHTF-1500K spiral tubeformer:This machine is also called as spiral tube forming machines, duct forming machine, HVAC duct machine, for producing round air duct for various uses, such as for HVAC round ducts, oval ducts, chimney flue, etc.
II Main advantages of ZHTF-1500K spiral tubeformer:
-- Special mould for various tube diameters, very easy to change and adjust, no need crane or too much manpower.
-- Large diameter range
-- High speed synchrony flying cutting system.
-- PLC control, convenient operation
-- Light and small, suitable for site work.III Main technical data of ZHTF-1500K spiral tubeformer:| Item | Data |
| Suitable spiral duct diameter range | 85~1500mm |
| Spiral duct length | No limited |
| Suitable material | Aluminum, stainless steel, galvanized steel, PPGI |
| Suitable material thickness | 0.4-1.0mm (can be specially ordered) |
| Suitable material width | 137-140mm |
| Material linear feeding speed | 1-38m/min |
| Main driving motor power | 5.5kW |
| Cutting motor power | 2.2kW |
| Compressed air needed | 0.8MPa |
| Control system | PLC + HMI |
| Machine dimension | 3500 x 2800 x 2580mm |
| Machine weight | About 2500kg |
Our factory has more than 10 years experience on spiral tubeformer machines in China. We can provide you good quality spiral tubeformer as well as good after-sale services.
Our company is an manufacturer and export agent, specialized in cold roll forming machines, metal processing machines, tube machines, pipe machines, transformer making machines, fin making machines, wire bending machines, motor making machines, tank making machines, welding machines, etc. We are supply our customers worldwide with our good qualities, competitve prices and satisfied after-sale services.
