PP-R high-speed pipe extrusion line used double separation PPR professional screw rod, reached low temperature efficient extrusion of effect; Professional design precision spiral shunt mold, make material flow distribution uniform, multilayer stack pressure, no shunt marks, head pressure low, guarantee melting material uniform meter out, used plate metering jacket which produced by Germany technology, can guarantee high-speed cooling requirement for PP-R pipe, 20mm PP-R pipe production speed can reached each 20 m/min.
Product applications:
1. Domestic hot and cold water piping systems;
2. Transmission, emission for industrial water and chemical substances;
3. Purified water, drinking water pipelines;
4, beverages, drug production transportation system;
5, compressed air tube;
6 pipe for industrial, agricultural, and other.
PP-r pipe mainly has the following features:
1, health, drug-free: This product is a green building materials, can be used for pure water, the drinking water pipeline system.
2, resistance to corrosion and scaling: Avoid pipeline corrosion caused by macular rust water sinks, bathtubs, and exemptions as a result of pipeline corrosion and scaling jams.
3, Proof high temperature and high pressure: Piped water temperature up to 95 ° C.
4, energy-saving insulation: Thermal conductivity only 1% of metal pipes, hot water pipe insulation for energy-saving effect is very good.
5, light weight: Just one-seventh of metal pipe.
6, pleasing in appearance: Smooth both inside and outside wall, small resistance for fluid, the color is soft, handsome in appearance.
7, reliable, easy to install: Use hot melt connection, a few seconds to complete, safe and reliable.
8, long life: Provides long-term continuous working pressure, using the life span of 50 years or more.
|
Model |
Pipe Dia(mm) |
Main extruder |
Mark-line extruder |
Speed(m/min) |
Output(kg/h) |
Total power(kw) |
Dimension
LXWXH |
|
JD-PPRG63 |
20-63 |
SJ65/33 |
SJ25/25 |
1-20 |
220 |
90 |
30X3.6X2.5 |
|
JD-PPRG160 |
75-160 |
SJ90/33 |
SJ25/25 |
0.6-6 |
300 |
150 |
36X3.6X2.5 |
Qingdao JIEDONG plastic machinery Co., Ltd is a professional manufacturer of plastic machinery, who is one knowledge-intensive manufacturer dedicated to extruder kind of equipment of scientific research, development, fabrication, sales and service.
Our company was awarded science and technology progress enterprise title by Qingdao government, also holds ISO9001: 2000 and CE certificate, and has independent import and export rights.
Plastic machinery we manufactured widely covers series extruder of plastic pipes; plastic plate &sheet; plastic profile; granulating unit; plastic recycle machine and crusher, more than 20types and have more than 100 varieties.
Our plastic machinery with top quality and company hold very good reputation, so our plastic machine lines had far sold to 30 provinces and cities in domestic market and had export to India, Russia, Korea, Iran, Saudi Arabia, Turkey and Vietnam.
Our products include plastic pipe production line, plastic profile production line etc
such as:
machine for PVC pipe, PE/HDPE pipe, PPR pipe, PA/PU pipe, corrugated pipe, COD duct, pre-stressed corrugated pipe, PE carbon corrugated pipe etc.
Machine for plastic profile include: PVC sheet, PVC corner bead, PVC profile, PET sheet, PET packing belt, WPC sheet, WPC door/winder board, WPC profile etc.
auxiliary machinery include: Mixer, drying machine, crusher, pelletizer etc
