Technical data:
1. Raw material: Wood pulp
2. Output paper: High grade toilet paper
3. Grammage: 13_30G/M2
4. Net paper width: 1760mm
5. Wire width: 2200mm
6. Capacity: 5T/D
7. Working speed: 150m/min
8. Rail gauge: 2900mm
9. Drive way: AC frequency conversion speed, section drive.
Main machine structure:
1. Cylinder part: Stainless-steel cylinder mould Φ 1500× 2200mm 1 set,
Pulp spray cylinder molding machine 1set, adjustable speed pulp roll make paper even, consistency: 0.1-0.15%. Wire mesh with more than 90-100layers. There is no pulp and vestige.
This make paper even and have strength of landscape orientation and portrait.
2. Couch roll: Φ 400× 2350× 2900mm, roll is made of seamless pipe, pipe width: 14mm, roll is covered with rubber, rubber width: 25mm, rubber shore hardness A30-35° .
3. Wire part is jointed by profiled bar, width of profile bar is 10mm.
4. Felt washer equipment of wire part: Water pressure piping schema, which can move, ceramics nozzle, which is hard to be worn.
5. Felt washing section: High pressure washer 2sets, water pressure piping schema, which can move, water pipe is made of stainless steel pipe with ceramics nozzle, which is hard to be worn.
6. Vacuum suction box: 4sets, one is beak pattern suction box with width of 150mm, the other three with width of 250mm, body of box is jointed by armor plate, material is polythene.
7. This Stander is box pattern cast iron stander, material is HT200, vertical bar is 400mm wide, it is special width, height of the bar of dryer is 400mm.
8. Dryer: Φ 2500× 2200× 2900mm, rubber shore hardness 210° , dryer is from Dandong in China.
9. Cylinder press knife use steam as power, including control box, steam drum.
10. Touch roll: Φ 550× 2350× 2900mm, cast iron roll is covered by robber, width of robber is 25mm, rubber shore hardness 93° Steam pressure.
Number |
Equipment |
Quantity(SET) |
1 |
5m3 high consistency hydrapulper |
1 set |
2 |
φ 380 double disk refiner |
2 set |
3 |
0.6 m2pressure screen |
1 set |
4 |
606disander(12sets) |
4groups |
5 |
φ 700 thruster |
4set |
6 |
8 inch pulp pump |
2 sets |
7 |
6 inch pulp pump |
6sets |
8 |
6 inch water pump |
2sets |
9 |
rewinding& perforated machine |
1set |
10 |
cutter |
1set |
No. |
name |
power(KW) |
degree |
quantity(set) |
1 |
1760paper making machine |
37 |
4 |
1 |
2 |
winding machine |
4 |
4 |
1 |
3 |
blower |
4 |
4 |
1 |
4 |
draft fan |
7.5 |
4 |
1 |
5 |
15vacuum pump |
22 |
4 |
1 |
6 |
hydrapulper |
55 |
4 |
1 |
7 |
double disk grinder |
37 |
6 |
2 |
8 |
pressure screen |
40 |
4 |
1 |
9 |
thruster |
11 |
6 |
4 |
10 |
8 inch pulp pump |
22 |
4 |
2 |
11 |
6 inch pulp pump |
2.5 |
4 |
6 |
12 |
6 inch pump |
11 |
4 |
2 |
13 |
rewinding & perforating machine |
2.2 |
Adjustable speed |
1 |
14 |
cutter |
1.5 |
4 |
1 |
15 |
air pump cabinet |
5.5 |
2 |
1 |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
