Reasonable and economic design, can be used in low ceiling garage
Low cable cover plate design, convenient for driving in and out
Dual-cylinder lifting system, stable and fast\
Cable-equalization system
Chain-driven system, faster lifting speed
Single or double manual lock release system, safe and reliable
Wear-resistant, heart-resistant and high strength macromolecular polyethylene slide blocks
Mold machining through the whole process so that the part are universal and interchangeable
Automatic arm lock release
Pass 120%capacity dynamic load test and 150% capacity static load test
Italian oil seal to make sure no oil leakage
Features:
Working noise ≤ 75dB ( A )
Rise time 45s
Drop time 40s
Motor power 2.2Kw/220 ~ 380V
Working pressure 14Mpa
Relative humidity 80%
Using altitude ≤ 1000m
Lifting capacity 8000lbs/3800kgs
Lifting height 1930mm
Clearance between posts 2791mm
Overall height 2776mm
20 container 24 sets
40 container 40 sets
Single point lock release Manual
|
Model NO. |
Lifting Capacity |
Lifting Height |
Overall Height |
Width Between Posts |
Rise /Drop time |
Power |
|
DTPF607N |
3200kgs/7000lbs |
1160mm |
1972mm |
2685mm |
30/25s |
2.2kw |
|
DTPF607 |
3200kgs/8000lbs |
1930mm |
2767mm |
2685mm |
45/40s |
2.2kw |
|
DTPF607S |
3200kgs/8000lbs |
1930mm |
2776mm |
2785mm |
45/40s |
2.2kw |
|
DTPF608 |
3200kgs/8000lbs |
1930mm |
2776mm |
2791mm |
45/40s |
2.2kw |
Qingdao Desiree Automobile Inspection Device Co., Ltd. is one of the leading companies that manufacture Auto-service equipments and parking system, which is a comprehensive company integrates R&D, production, promotion and trading with foreign companies.
The company is located on the west bank of the beautiful coastal city Qingdao, near by the Tongsan Highway, Qingdao International Airport, Jiao-Ji Railway. And it is only 20 minutes' drive to the Qianwan Harbor_the biggest container habor in Asia. Our company covers an area of 120, 000 square meters, of which a building area of 50, 000 square meters, with 837 workers, including one design and technology team with 96 specialists. In 2010, the companies' annual revenue is 320 million RMB.
Our company supplies all kinds of auto-service equipments with high added value. We have exported our products to more than 80% countries in Europe, south America and north America, besides we have agent over 50% countries in Asia, Africa and Oceania. The sales of this year is expected to increase by 100% than last year. Our main products include 2 post auto lifts, 4 post auto lifts, scissors lifts, four wheel aligner, auto collision repair system, wheel balancer and tyre changer etc.
With talented personnel, advanced technology and equipment advantages, our company developes and manufactures a series of good products to cater for the need of the customers and make a contribution to solving urban parking problem. We can manufacture all kinds of parking system, including vertical_horizontal parking, speedy parking, stacker parking, easy parking and so on. We specialize in technology research and development, design and manufacturing, installation, training and after sales service for parking system.
"Repay Society, Share Profit" is our tenet. We have perfect sales service system and quality control system, modernized scientific management system by insisting on the conception of management" human centered, market oriented, taking science and technology as driving power, taking quality as life, taking innovation as the soul, benefit focused and guarantee by management". Excellent product quality and good reputation bring the brand effect to our company. Demand exceeds supply much. And sales revenue, profits and taxes go up year by year.
We gain all kinds of qualification certificate and passed through parking system production license, special equipment installation and repair license, ISO9001 international quality certificate, China compulsory certificate, Europe CE certificate and so on.
We will provide you the most qualified products and most pure-hearted service with continuous effort.
