Wire Drawing Machine with Annealer (HXE-22DT)

Wire Drawing Machine with Annealer (HXE-22DT)
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T

fine wire &cable drawing machine with continous annealer -high productivity
Specification
1.inlet size:0.8mm-1.6mm
2.outlet size:0.25mm-0.6mm
Main technical parameter

Usage

fine copper wire drawing and annealing

Inlet diameter

0.6mm-1.2mm

Outlet diameter

0.1mm-0.32mm

Max. mechanical speed

2000m/min

Dies

22dies

Slip ratio

15%, Finished capstan slip ratio: 8%

Main motor

AC 3 Phase 15KW

Take up motor

AC 3 Phase 5.5 kw

Take up capacity

50kg for diameter 300mm iron spool

Spool size

diameter 300mm/Max (customize)

Capstans

tungsten carbide coated

Capstan lubrication

Spray

Traversing

110W synchronous motor,transmission by timing belts

Brake

20KG-M Electromagnetic brake

Air pressure

4-6kg/cm2

Annealing pulley

diameter 120mm

Annealing volt

DC0~50V

Annealing current

DC600A

Annealing motor power

30KVA

Power source

(customize)

Spool control

PID

Tension control

Weight balance

Machine weight

3200kg



Certificaation
in exhibition



Inverter : Invoance

Motor :Wannan

Precision resistance: WDD military enterprise

Bearing :NSK

Low voltage equipment: France Schneider


Warranty

6 month for electrical part

12 month for mechanical part


After-sell service

Pre-sale training:In order to guarantee the customers are able fully to operate the rod breakdown machine , if the customer need, we can help customer training, includes:

(1) Correct operating mode

(2) Correct maintenance way

(3) Remove simple problem
Prod Model: HXE-22DT
Markets: South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Color: Customized
Aftersales Service: Engineer Is Available Overseas
Usage: Wire
Type: Fine Wire Drawing Machine with Annealer
Outlet Diameter: 0.1mm-0.32mm
Max.Inlet Wire Dia.: 0.6mm-1.2mm
Block Dia.: 250mm
Max. Number Of Block: 22
Suzhou Hengxie Machinery Co., Ltd. Locates in Yinghu Industrial Zone, Wangting town, Suzhou Hli-New District, near to G312 with a conveninet transportation and nice environment. It is a professional company which specializes in electronic cable, electromagnetic cable, electrical wire eat. It is at a leading position in this line because of the topping managing talent and advanced technics.

Hengxie has invested RMB ten Millons to introduce the Germany equipments and technics and developed the cable producing line by itself. This ensures the quality stable and capability superior. Hengxie has successfully set up a superior enterprise mode.

With the mange concept"Stable Quality, Mutual Development" Hengxie warmly welcome alll the friends to grant the changefor sincere cooperation and win the mutual benifit in the future.
