Wire Drawing Machine with Annealing (HXE-14DT)
| Price: |
Negotiable/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union |
HXE-14DT fine wire drawing machine with annealing
Drive: Double inverters control
Drawing Dies Number: 14
Input diameter: Φ 1.6_Φ 0.8mm
Output diameter: Φ 0.6_Φ 0.25 mm
Drawing speed: MAX1500m/min
Slip ratio of machine: 15%
Slip ratio of fix speed capstan: 8%
Frame: Welded by steel plate with backfire
Drawing wheel: Carbonization tungsten
Main motor power: 15KW
Take up motor power: 5.5KW
Capstan diameter: Φ 316mm
Fix speed capstan diameter: Φ 268mm
Annealing wheel length: Φ 260mm
Annealing voltage: DC0~60V
Annealing current: DC600A
Annealing protect type: Steam
Spool size: 300mm
Loading copper weight: 50kg
Take up type: Shaft type
Transmission type: Flat belts
Loading capacity: 50KG
Lubrication type: Spray type
Brake: Magetic brake
Power source: 380V50/60Hz
Machine weight: 2900KG
Machine compositions:
14DT drawing machine
Electrical control cabinet
Steam generator
Pay off stand
Spare parts
| Prod Model: |
14DT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inlet Diameter: |
0.8-1.6mm |
| After Service: |
Engineer Available to Overseas |
| Size: |
2900*1300*1800 |
| Machine Weight: |
2950kg |
| Warranty: |
1 Year |
| Popularity: |
Hot/on Sales |
| Color: |
Blue/Customized |
| Dies: |
14 |
| Operation: |
Button Control |
| Usage: |
Rope Wire |
| Type: |
Copper Wire Drawing Machine with Annealing |
| Outlet Diameter: |
0.25-0.7mm |
| Max.Inlet Wire Dia.: |
0.8mm-1.6mm |
| Max. Number Of Block: |
14 |
Suzhou Hengxie Machinery Co., Ltd. Locates in Yinghu Industrial Zone, Wangting town, Suzhou Hli-New District, near to G312 with a conveninet transportation and nice environment. It is a professional company which specializes in electronic cable, electromagnetic cable, electrical wire eat. It is at a leading position in this line because of the topping managing talent and advanced technics.
Hengxie has invested RMB ten Millons to introduce the Germany equipments and technics and developed the cable producing line by itself. This ensures the quality stable and capability superior. Hengxie has successfully set up a superior enterprise mode.
With the mange concept"Stable Quality, Mutual Development" Hengxie warmly welcome alll the friends to grant the changefor sincere cooperation and win the mutual benifit in the future.
