| Products models | D22T | D24T |
| Revolving speed | 2000m/min | 2000m/min |
| Main motor | 15kw | 11kw |
| Take-up drive motor | 5.5kw | 3.7kw |
| Inlet wire | 0.8—1.2mm | 0.5—1.2mm |
| Finish dia | 0.1—0.32mm | 0.08—0.25mm |
| Spool capaticy | 50kg | 50kg |
| No. of dies | 22 | 24 |
| Annealing capacity | 12KVA | 12KVA |
| Reduction rate | 15% | 13% |
| Brake | Magnetic brake | Magnetic brake |
| Power source | 380V 50HZ | 380V 50HZ |
| Dimension | 2600*1600*1900 | 2600*1600*1900 |
Yancheng AIJIN electrical machinery Co., Ltd adheres to the company spirit of "scientific and technological innovation, more professional and stronger" and strives to make the advanced, efficient and easy operation machines. "AIJIN"brand will become an international famous brand with the development of your enterprise!
