Features:
High Speed, Saving Electricity
Automation:
Automatic
Structure:
Horizontal
Computerized:
Computerized
Plastic Type:
Thermoplastic
Type:
Injection Molding
Product Description
Product Description
We are professional plastic injection molding machine manufacturer for all kinds of production requirements, Clamping force from 50 to 12700T , injection weight from 50 to 10000g . with best price/ performance ration of any machine on the market.
Some of the important features:
Clamping system: Faster response, stable and high rigidity
Injection system: Accurate and flexible, lower rejection rate
Control system: Computer and simple operation,molding data memory system
Power system: Energy saving, high efficient and precise
Metal parts: The thickness of our frame, metal plate and wallboard are thicker than other company.
Other Information
Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production
Visiable lubrication system: on time clean, avoid cast steel parts abrasion and broken.
Oil treasure: Filter of hydraulic oil,good for pump and valves
Long working life: Imported spare parts and updated version
Aftersales service: Professional & timely
Delivery time:30-60 days
Port of dispatch: Shanghai
INJECTION UNIT
Unit
WMK-1700
A
B
C
Screw Diameter
Mm
130
140
150
Screw L/D Ratio
L/D
24
22.3
20.8
Short Size
Cm3
8266
9586
11006
Injection weight
G
7520
8723
10015
oz
244
284
325.6
Injection Pressure
Mpa
164
142
123
Screw Speed
Rpm
100
CLAMPING UNIT
Clamp Force
KN
17000
Space Between Tie Bars
mm
1500*1350
Toggle Stroke
mm
1520
Max. Mold Height
mm
1500
Min. Mold Height
mm
700
Ejector Stroke
mm
350
Ejector Tonnage
KN
318
OTHERS
Max. pump Pressure
Mpa
16
Pump motor powder
Kw
45+45+45
Heater Power
Kw
92
Oil tank capacity
L
2500
Machine Dimension(L*W*H)
M
15*3.4*3.6
Machine Weight
T
112
