North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:
Injection Blow Molding
Structure:
Vertical
Plastic Type:
Thermoplastic
Plasticizing Way:
Screw Type
Clamping Way:
Mechanical
Automation:
Automatic
Computerized:
Computerized
Certification:
CE
Product Description
Pplicable scope: Unicolor/bicolor sole/shoelace, small plastics, sole test mold proofing, complement, leather sole injection molding, inserts injection. Applicable material: TR, TPU, TPR, PVC, SEBS and so on
Main Feature 1. Siemens PLC control system allows the machine z stable work. 2. Schneider Electric parts ensure the electric control system of the machine stable and reliable. 3. Mitsubishi fluency converter makes the mobile material shoot gun more quick, stable and accurate. 4. Dofluid hydraulic valve ensure the oil circuit smooth and stable. 5. Crane connecting bar die molding allows stable mold clamping force. 6. Rapping bar turn over automatically, counterdie shifts out to ensure easiness, convenience, and quickness of taking out the products, mold inserting. 7. Push-out automatically and no product detormation in ensured, fully reducing the work intensity of the operator. 8. Open touch panel allows a at any time control on operating condition and a diagnosis of abnormal condition. 9. Template and mold are cooled by water, which increase the output. 10. Lubricate automatically to make up the shortage of manual maintenance and to lengthen the life time of the machine. 11. The machine has four safety devices, operated by machine, electricity, water and air, which ensure the operation safe. 12. Servo motor sharply saves power energy consumption.
ltem
Unit
HC_T0202-D
number of Station
Statian
2
Clamping
Ton
220
Mould Dimensions
mm
300x400
Max.Opening stroke OF the Mold
mm
350
Argles of Rotating head
0°-90°
Screw Diameter
mm
65
Screw speed
rpm
0-185
Thermal zone of barrel
No.
3+1
Injection pressure
mpa
95
Injection volume
Cm3
860
Length-diameter ratio L/D
L/D
22
Extrusion unit
Kw
13
Max.electric consumption
Kw
45.5
The average power consumption
Kw
28
Measurement L*W*H
Mm
4300*3400*2500
Weight approximate
ton
9
