Function:
Marking, Engraving
Material:
Ceramics, PVC, Wood, Paper and Other Nonmetal
Product Description
CO2 Marking Laser Machine
Application Materials: Most of Non-metallic materials, such as, ceramics, PVC, ABS, acrylic, plastic, bamboo, organic materials, epoxide resin, glass, wood, and paper, etc.
Field: Woodworks, gifts, electronic components, clothes, leather, paper, medicines, food and package, etc.
Advantages 1, Superior quality CO2 laser beam, stable light and low failure rate 2, With the excellent servo motor, the high-speed scanning galvanometer is of high marking speed and precision. 3, Adopt industrial control computer, strong resisting disturbance capacity, assuring the long stable working. 4, Easy operation software, compatible for all formats from CorelDraw, Photoshop, AutoCAD, etc. 5, Reasonable whole structure design, better stability and higher reliability. 6, SYNRAD / COHERENT tube can be refilled, excellent performance, Max. 45000 hours' life without maintenance 7, Be applicable to flying marking production line.
Parameters
Unit
Data
Data
Type
CKD-CMLA-10/30
CKD-CMLA-50
Power
W
10/30
50
Laser
CO2 laser
CO2 laser
Laser Wavelength
nm
1064
1064
Optional Marking Area
mm
50*50/100*100/110*110/200*200/300*300
50*50/100*100/140*140/200*200/300*300
Marking Speed
mm/s
≤7000
≤7000
Repeated Frequency of Laser
KHz
<=100
<=100
Marking Type
Dynamic Mark / Static Mark
Dynamic Mark / Static Mark
Minimum Line Width
mm
0.1
0.15
Minimum Character
mm
0.3
0.4
Controller (Software - EzCad)
JCZ from China
JCZ from China
Life-span of Fiber Laser Module
h
45000
45000
System Operation Environment
WindowsXP/2000/Windows 7-32/64bits
WindowsXP/2000/Windows 7-32/64bits
Cooling Mode
Air cooling
Air cooling
Temperature of Operation Environment
ºC
15~35
15~35
Voltage
220V/50Hz/single phase/10A
220V/50Hz/single phase/15A
Power Requirement
W
12000
15000
Computer Requested
with desktop computer
with desktop computer
Communication Interface
USB
USB
Dimension (L*W*H)
mm
700*650*1200
750*700*1300
Weight
Kg
150
150
CKD is located in Shenzhen - one of the most energetic and creative city in China, in 2007, the factory was established. CKD specialize in the research, development, and produce the customized laser equipment. We have a professional and energetic R&D team, strictly follow the ISO9001: 2000 quality management system, pursue high-tech, high quality, and high customer satisfaction products, to seek long-term cooperation and common development customers.
Our main customized products: Marking Laser Machine, including: Portable Marking Laser Machine, Table Marking Laser Machine, Rotary Multi-station Marking Laser Machine, Sealing Marking Laser Machine, UV Marking Laser Machine, CO2 Marking Laser Machine; Welding Laser Machine; ITO Laser Machine; Slicer Laser Machine; Cutting Laser Machine; And a lot of self-developed laser equipment device.
Our laser equipment are widely used in industries of hardware tools, solar energy, auto accessories, electronics, electric appliance, medical, glasses, leather, optical accessories, advertising, commodity, communication, sheet metal industry, jewelry industry, kitchenware, jet coding and crafts gifts etc.
Company concept: All participate in and strive together to creative our future
Quality policy: Based on customer satisfaction; Armed high quality by high-tech.
Welcome new customers' attention and thank old customers' support! We will as always provide and feedback you the higher performance, cost-effective, better quality products and timely service.
