Function:
Marking, Engraving
Material Example 1:
Monocrystalline Silicon Chip, IC Grain, Sapphire
Material Example 2:
Glass, TFT, LCD, Textile, Ceramic, and So on
Product Description
UV Marking Laser Machine
Application Materials: Marking on stainless steel, brass, aluminum, anodized aluminum, iron, gold, silver, titanium and other metals, marking on plastic, ABS, acrylic, Nylon, PVC, marble, ceramic etc. Black and white marking on most metals and plastics, black marking on anodized aluminum, color marking on stainless steel and titanium.
Advantages 1, Precision high up to 0.0012mm. 2, Superior laser beam, the definition is 1 micron, 10 times than traditional products. 3, No consumables within 10 years. 4, High speed, 7000mm /s, 3 to 5 times than traditional products. 5, The fiber laser beam directly comes out from the fiber device, don't need adjust laser optical path. 6, Original JCZ controller, USB interface, swift and stable transmission, easy software operation, strong functions. 7, High-quality scan head, with good seal, capable to prevent dust and water, small volume, compact and solid. 8, Compatible for all formats from CorelDraw, Photoshop, AutoCAD, etc. 9, Integrated Air Cooling System: The cooling effect is more excellent than the water cooling effect in YAG laser, free maintenance.
Parameters
Unit
Data
Data
Type
CKD-UMLA-3
CKD-UMLA-5
Power
W
3
5
Laser
UV laser
UV laser
Laser Wavelength
nm
1064
1064
Optional Marking Area
mm
50*50/100*100/150*150/200*200/300*300
50*50/100*100/150*150/200*200/300*300
Marking Speed
mm/s
7000
7000
Minimum Line Width
mm
0.015
0.015
Minimum Character
mm
0.2
0.2
Controller (Software - EzCad)
JCZ from China
JCZ from China
Life-span of Fiber Laser Module
h
100 000-200 000
100 000-200 000
Beam Quality
M2
<1.6
<1.6
Focus Spot Diameter
mm
<0.01
<0.01
Power Stability (8h)
rms
<±1.5%
<±1.5%
System Operation Environment
Windows XP / Windows 7 / Windows 8
Windows XP / Windows 7 / Windows 8
Cooling Mode
Air cooling
Air cooling
Temperature of Operation Environment
ºC
15~35
15~35
Voltage
220V/50HZ/1-PH or 110V/60HZ/1-PH
220V/50HZ/1-PH or 110V/60HZ/1-PH
Power Requirement
W
<500
<500
Computer Requested
with PC
with PC
Dimension (L*W*H)
mm
550*600*600
550*600*600
Weight
Kg
70
70
CKD is located in Shenzhen - one of the most energetic and creative city in China, in 2007, the factory was established. CKD specialize in the research, development, and produce the customized laser equipment. We have a professional and energetic R&D team, strictly follow the ISO9001: 2000 quality management system, pursue high-tech, high quality, and high customer satisfaction products, to seek long-term cooperation and common development customers.
Our main customized products: Marking Laser Machine, including: Portable Marking Laser Machine, Table Marking Laser Machine, Rotary Multi-station Marking Laser Machine, Sealing Marking Laser Machine, UV Marking Laser Machine, CO2 Marking Laser Machine; Welding Laser Machine; ITO Laser Machine; Slicer Laser Machine; Cutting Laser Machine; And a lot of self-developed laser equipment device.
Our laser equipment are widely used in industries of hardware tools, solar energy, auto accessories, electronics, electric appliance, medical, glasses, leather, optical accessories, advertising, commodity, communication, sheet metal industry, jewelry industry, kitchenware, jet coding and crafts gifts etc.
Company concept: All participate in and strive together to creative our future
Quality policy: Based on customer satisfaction; Armed high quality by high-tech.
Welcome new customers' attention and thank old customers' support! We will as always provide and feedback you the higher performance, cost-effective, better quality products and timely service.
