Belling Type:
Straight Type and R Type
Belling Range:
Od50mm-160mm
Heating Box:
Two
PLC:
Siemens
Touch-Screen:
Siemens
Working Method:
Full Automatic
Certification:
SGS
Automation:
Automatic
Product Type:
PVC Pipe
Computerized:
Non-Computerized
Product Description
SGK-160 Conduit Belling Machine is specially used for belling of PVC pipes with ODΦ 50-160mm. The pipe belling type: Straight type and R type. After shaping, both vacuum calibration technology inside the mould and force air/water cooling outside of pipe are adopted to ensure precise belling size. The machine can be used on complete extrusion line with PLC control. The greatest feature of this machine is the length of the supporting table, about 8m, suitable for the pipes in 3m to 6m.
Main technical parameters
pipe expand range
( out diameter )
Φ50-160mm
Belling type
U type , R type and square type
Oil label
No.46/hydraulic oil
Quantity of heater
2
Heating power
8kw
highest temperature in heater
280
Air pressure
0.4~0.6Mpa
Cooling water pressure
0.2~0.3Mpa
Total power/Capacity
22kw
Pipe length
3-6m
Center height
1000mm±50mm
Machine set weight
2.5T
