Materail:
304
Weight:
5t ~ 18t
Type:
Extrusion Blow Molding Machine
Raw Material:
PET
Making Method Of Parison:
Multilayer Blowing
Automation:
Automatic
Computerized:
Computerized
Certification:
ISO9001:2008
Product Description
Introduction & Process: The full automatic rotary stretch blow molding machine is widely used for the blowing plastic container (including hot Filling bottle), suitable for the product of water, tea drink, dairy, fruit juice, carbonated beverage and pharmaceutical Injection etc. With the structure of multi-mold in one machine, can complete the actions of preform unscrambling, Preform feeding, heating, feeding, stretch, blowing, cooling and bottle conveying etc full automatically. The main Components on the machine are of international famous brand. The machine owns the advantage of high automation, Reliable and stable operation and low power consumption.
Name
Item
Data
Specification of Bottle
Bottle Capacity
0.2~2.0Liter
Max. Body Diameter
120mm
Max. Height of Bottle
320mm
Max. Diameter of Bottle Mouth
50mm
Max. Preform Height
145mm
Mould
Mould Cavity
16Cavities
Output
500ml bottle (Cold filling bottle)
20, 000pcs/h
Rate of finished product
≥ 99.7%
Cooling System
Water inlet temperature
10
Water inlet pressure
5.0~6.0Mpa.
Flow Rate
250L/min
Cooling Capacity
20P
Air Source
High pressure
3.5~4.0Mpa
Blowing air flux
14m³ /min (500ml)
Low pressure
0.8~1.0Mpa
Blowing air flux
3.5~7.0m³ /min
Filtering grade
0.01micron
Humidity
Dehumidified
Dimension of Machine
L × W × H (Blowing)
2350× 3310× 3150mm
Weight (Blowing)
9000KGS
L × W × H (Oven)
4200× 1250 × 2200mm
Weight
2000KGS
Motor Power
Total Power
216kW
Main Motor
4kW
Really Power Use
35-70kw
HY-FILLING, as one of famous beverage and dairy packaging machinery manufactures in China, it is located in Zhangjiagang city which is very near Shanghai with beautiful scenery and convenient transportation. Owning the top-ranking R&D center and more than 20 senior engineers and 30 senior technicians, our products has covered all the domestic markets. Furthermore, we have exported our products all over the world, such as American, Argentina, Brazil, Russia, Poland, Turkey, Iran, South Africa, and Southeast Asia, etc, and more than 600 filling lines running all over the words till to now. We also offer our customers with the best technical plan, superior products, and perfect after-sale service to optimize the process of production, and supply our customers with reliable machinery. With persistent development, now our company is becoming larger and larger, thanks for your support and trust on our machinery. We consider "Exploring the highest technology in machinery industry; Creating a brilliant future in this field" as our company policy. And we deeply believe that tomorrow of HUAYU COMPANY will be much more brilliant.
Main Products:
1.2000-48000 BPH Mineral/Pure Water Bottling Line;
16. Film Shrink-wrapping or Carton Box Packaging Machine;
17. PA-Depalletizer;
18. Turn Key Project.
