Type:
PP Film Blowing Machine
Certification:
CE
Automation:
Automatic
Raw Material:
PP
Computerized:
Non-Computerized
Maximum Folding Width Of Film:
600mm
Screw Diameter:
60mm
Product Description
PP Film Blowing Machine
1. This screw material cylinder is elabroately made of 38CRMOALA alloy steel after nitrogen treatment and has best rigidity and corrosion resistance.
2. The mould head is plated with hard chroming and has screw mandrel structure with uniform and smooth material discharing. And the aircooled device has labyrinth lype structure with characteristic as uniform air-jut quantity, automatic temperature control and automatic heating.
OPTIONAL EQUIPMENT
1) AUTO LOADER
2) FILM SURFACE TREATER
3) DIE ROTARY DEVICE
4) AIR COMPRESSOR
Main Technical Variables:
Type
SJPP55
SJPP60
SJPP70
Diameter of screw
Φ55
Φ60
Φ70
L/D
28:1
28:1
28:1
Folding width of film(mm)
100-500
100-600
300-800
Single-face Thickness of film(mm)
0.01-0.1
0.01-0.1
0.01-0.1
Max. Extrusion(kg/h)
30
45
60
Power of main motor(kw)
11
15
18.5
Power of Traction motor(kw)
1.1
1.1
1.5
Length of Traction roller(mm)
550
650
850
Outline diameter(L×W×H)
4500×2000×3500
4800×2500×3800
5000×2800×4000
Weight(T)
3
4
5
Name: Ruian Fangtai Machinery Co., Ltd
Year Established: 1987
Registered asset: RMB81, 000, 000.00
Workers: 50-200
Management Personnel: 58
Technicians: 38
Chief Engineer: 10
Engineer: 38
Turnover: RMB100million (Year 2007)
The First Factory Area: 20, 000square meters
The Seconday Factory Area: 5, 000 square meters
Certificate: ISO9001, CE
Main Products: Flexo printing machines, casting machines, bubble film making machines, film blowing machines, computer control bag-making machines, slitting machines,
Principle: Good quality, best services, and competetive price
Market: East Europe, North America, South America, Asian, Africa, The Middle East, etc
Located city: Ruian city, Zhejiang Province, PR China
