Sjpp Rotary Die Head PP Film Extruder (CE)
Price: |
US $ 13000-22000/Set |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Set |
Pay Type: |
L/C,T/T |
Prod Model: |
SJPP |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
PP Film Blowing Machine |
Certification: |
CE |
Automation: |
Automatic |
Raw Material: |
PP |
Computerized: |
Non-Computerized |
Maximum Folding Width Of Film: |
500mm |
Screw Diameter: |
55mm |
Product Description
PP Film Blowing Machine
1. This screw material cylinder is elabroately made of 38CRMOALA alloy steel after nitrogen treatment and has best rigidity and corrosion resistance.
2. The mould head is plated with hard chroming and has screw mandrel structure with uniform and smooth material discharing. And the aircooled device has labyrinth lype structure with characteristic as uniform air-jut quantity, automatic temperature control and automatic heating.
OPTIONAL EQUIPMENT
1) AUTO LOADER
2) FILM SURFACE TREATER
3) DIE ROTARY DEVICE
4) AIR COMPRESSOR
Main Technical Variables:
Type
|
SJPP55
|
SJPP60
|
SJPP70
|
Diameter of screw
|
Φ55
|
Φ60
|
Φ70
|
L/D
|
28:1
|
28:1
|
28:1
|
Folding width of film(mm)
|
100-500
|
100-600
|
300-800
|
Single-face Thickness of film(mm)
|
0.01-0.1
|
0.01-0.1
|
0.01-0.1
|
Max. Extrusion(kg/h)
|
30
|
45
|
60
|
Power of main motor(kw)
|
11
|
15
|
18.5
|
Power of Traction motor(kw)
|
1.1
|
1.1
|
1.5
|
Length of Traction roller(mm)
|
550
|
650
|
850
|
Outline diameter(L×W×H)
|
4500×2000×3500
|
4800×2500×3800
|
5000×2800×4000
|
Weight(T)
|
3
|
4
|
5
|
Name: Ruian Fangtai Machinery Co., Ltd
Year Established: 1987
Registered asset: RMB81, 000, 000.00
Workers: 50-200
Management Personnel: 58
Technicians: 38
Chief Engineer: 10
Engineer: 38
Turnover: RMB100million (Year 2007)
The First Factory Area: 20, 000square meters
The Seconday Factory Area: 5, 000 square meters
Certificate: ISO9001, CE
Main Products: Flexo printing machines, casting machines, bubble film making machines, film blowing machines, computer control bag-making machines, slitting machines,
Principle: Good quality, best services, and competetive price
Market: East Europe, North America, South America, Asian, Africa, The Middle East, etc
Located city: Ruian city, Zhejiang Province, PR China
