10 Molds Vertical Rotation popsicle bottle/bag making machine/ice pop/jelly bag-Full automatic
Bottle Types could be produced:
This rotational blow molding machine is suitable to produce ice pop bag, ice popsicle bag, ice lolly bag, LDPE bags.
Material could be used:
PE/PP/HDPE/LDPE
Style of Machine:
Rotational verticle, 10 molds available.
Sanqing has the best quality of rotational blow molding machine.
Work Speed:
Very fast, it could reach 5000 bottles per hour
Save Electricity:
No hydraulic used, it is pneumatic machine, so it save electricity.
Deflashing:
Deflashing device is provided, it could deflash the bubble very quickly.
Video is Ok to provided upon request.
|
Parameter |
Model: Vertical rotation style automatic blow molding machine SQ-10 |
|
Screw Rod Extruder Dia.(mm) |
55 |
|
Weight(KG) |
3000 |
|
Motor Power(KW) |
10.5 |
|
Dimension(L, W, H) |
3.5 x 1.6 x 2.4 |
|
Applicable Material |
PE/PP |
|
Air Consumption(m3/min) |
0.4 |
|
Air Pressure(mpa) |
0.5-0.6 |
|
Output(pcs/hour) |
5000 |
|
Heating Power(KW) |
8 |
Cangzhou Sanqing company is a manufacturing group, it includes two kinds of main products: Stainless steel press fitting, blow molding machines. It also export some other valuable products such as tire valves.
We have two main plants, one is for stainless press fitting, another plant is for blow molding machine.
Stainless steel press fitting includes stainless pipes, stainless press fittings, size range since DN15-DN100. It includes raw material: SUS304 and SUS316L. The stainless steel press fitting already been used for many years in the market and it is under process to develop more international markets. Sanqing is one of the leading manufactures for stainless steel press fittings.
Blow Molding machine is another main products, it including pneumatic type blow molding machine and hydraulic blow molding machine. The machines are able to produce hollow products since 1 ml to 40 Liters. Nowadays, our machines are already full of China and Sanqing brand is a famous brand for this plastic field.
Rotational blow molding machine, or we call it rotational bottle making machine is the star machine and main machine, since it has been developed, it has been improved gradually, now it is a very successful machine and shipped to many foreign countries such as: Russia, Mongolia, Pakistan, India, Malaysia, Kenya, South Africa, Brazil, Mexico, Paraguay, Dominican Republic etc.
So Sanqing brand is keep on growing and hope we could cooperate together to grow together.
