Automatic Extruding Plastic Blow Molding Machine/One Stage Blow Moulding Machine/PE Blow Molding Machine/Automtaic Vacuum Shape Blowing Machine/Hollow-Plastic Blow Molding Machine/HDPE Blow Moulding Machine/Plastic Bottle Moulding Machine/One stage with 1station Moulding Machine
JMX60 single station extrusion blowing machine is designed for blowing 6L (max) bottle.It has 1 blowing die. Transducer is used to adjust the speed continuously, PLC and touch screen are used for controlling. All electronic and pneumatic components are from the band names.
The Machine Can Produce all kinds of PE Container, such as PE Bottles, PE Barrels, PE Kettles.
| Specifications |
| JMX 60 |
| Material |
| HDPE |
| container volume | L | 1gallon |
| Number of die |
| 1 |
| Output | pc/h | 100 |
| Dimension(L*W*H) | M | 3.5*2.2*2.8 |
| Weight | KG | 5500 |
|
| Clamping Unit |
| JMX 60 |
| Clamping force | KN | 70 |
| Platen opening stroke | mm | 188-538 |
| Platen size | mm | 338x450 |
| Max mould size(W*H) | mm | 450x500 |
| Mould thickness | mm | 190-300 |
|
| Power |
| JMX 60 |
| Max drive | KW | 20.5 |
| Total power | KW | 33.9 |
| Fan power for screw | KW | 0.3 |
| Air pressure | Mpa | 0.7 |
| Air consumption | m³/min | 0.6 |
| Average energy consumption | KW | 12.5 |
|
| Extruder unit |
| JMX 60 |
| Screw diameter | mm | 60 |
| Screw L/D ratio | L/D | 25 |
| Plasticising capacity | Kg/hr | 60 |
| Number of heating zone | zone | 3 |
| Extruder heating power | KW | 8.8 |
| Extruder driving power | KW | 15 |
|
| Die |
| JMX 60 |
| Number of heating zone | zone | 3^5 |
| Power of die heating | KW | 4.6 |
| Central distance of single diehead | mm | 150 |
Main parts list:
| Electrical system |
| JMX 60 |
| Touch screen |
| HITECH |
| PLC |
| MITSUBISHI |
| Transducer |
| MITSUBISHI |
| Temperature controller |
| OMROM |
| Low pressure electrical |
| YangMing |
| Relay |
| Schneider |
| Button switch |
| Schneider |
| Motor |
| SIEMENS |
| Contactor |
| Schneider |
| |
| Hydraulic ystem |
| JMX 60 |
| Oil pump |
| YUKEN |
| Hydraulic pressure valve |
| YUKEN |
| Hydraulic pressure tube |
| KIMBERLEV |
| Airproof |
| VALAVA |
|
| Pneumatic system |
| JMX 60 |
| Pneumatic component |
| FESTO |
Zhangjiagang King Machine Co., Ltd. is a group company located in Zhangjiagang city Nanfeng industrial town, we have more than 15years experiences on beverage machinery and plastic machines.
We devote ourselves to the development, research and production of plastic machine and liquid food and beverage packing and filling industry and automatic blow molding machine in China.
Our Main products including: Mineral water and purified water producing line. Carbonated beverage producing line. 3 gallons& 5gallons producing line. Flat and tube UHT device, and CIP system. All the products are sold well in every province and city of the whole country and also exported to about thirty countries and areas with strong technical force, advanced equipment, scientific management system and perfect after-sales service.
