Features:
1. Adopt automatic design. The energy consumption is 40% less than hydro-dynamically operated, with no pollution of oil leaking.
2. The design of accessory and component is deft and speed in performance.
3. PLC control the action routine.
4. Operated easily. It is suitable for the hollow product with in 5000ml.
5. Two extruders can be working together acoording to the customers demand, blowing product with liquid level line.
![]()
|
Technical parameter of CSD-EB90J2/10L Double station(Multiple cavity for small bottle) Extrusion Blow Molding Machine |
|
Model |
Unit |
CSD-EB90-J2-A1 |
CSD-EB90-J2-A2 |
CSD-EB90-J2-A3 |
CSD-EB90-J2-A4 |
CSD-EB90-J2-A6 |
CSD-EB90-J2-A8 |
|
Screw Diameter |
mm |
90 |
90 |
90 |
90 |
90 |
90 |
|
Extrusion Capacity PP,PE |
kg/h |
220 |
220 |
220 |
220 |
220 |
220 |
|
PC.PVC |
|
|
|
|
|
|
|
|
Dry Cycle |
s |
12 |
12 |
12 |
12 |
12 |
12 |
|
Screw Diameter |
L/D |
28:1 |
28:1 |
28:1 |
28:1 |
28:1 |
28:1 |
|
Mold Center Distance |
mm |
|
240 |
170 |
130 |
130 |
130 |
|
Screw Rotating Speed |
R/min |
10-85 |
10-85 |
10-85 |
10-85 |
10-85 |
10-85 |
|
Mold Stroke |
mm |
300-560 |
300-560 |
300-560 |
300-560 |
300-560 |
300-560 |
|
Max. Mold Dimension(W×H) |
mm |
550×475 |
550×475 |
550×475 |
550×475 |
550×475 |
550×475 |
|
Length of Mold Capacity |
mm |
600-750 |
600-750 |
600-750 |
600-750 |
600-750 |
600-750 |
|
Drive Motor Capacity |
kw |
55 |
55 |
55 |
55 |
55 |
55 |
|
A |
107 |
107 |
107 |
107 |
107 |
107 |
|
Hydraulic Pump Capacity |
kw |
22 |
22 |
22 |
22 |
22 |
22 |
|
A |
44.7 |
44.7 |
44.7 |
44.7 |
44.7 |
44.7 |
|
Number of Heaters |
|
4 |
8 |
10 |
12 |
12 |
12 |
|
Heating Capacity |
kw |
36 |
40 |
42 |
49 |
49 |
49 |
|
A |
58 |
65 |
67 |
77 |
77 |
77 |
|
Clamping Force |
T |
20 |
20 |
20 |
20 |
20 |
20 |
|
Weight of Product |
G |
350-3500 |
100-3500 |
100-3500 |
100-3500 |
100-3500 |
100-3500 |
|
Max. Product Capacity |
L |
10 |
8 |
4 |
2 |
0.8 |
0.3 |
|
Total Electric Power |
KW |
113 |
117 |
119 |
126 |
126 |
126 |
|
Weight |
kg |
13500 |
13500 |
13500 |
13500 |
13500 |
13500 |
|
Dimension |
L×W×H(mm) |
4000×4700×3300 |
4000×4700×3300 |
4000×4700×3300 |
4000×4700×3300 |
4000×4700×3300 |
4000×4700×3300 |
|
Transfer Displacement Stroke |
mm |
720 |
720 |
720 |
720 |
720 |
720 |
|
Air Pressure |
kg/cm |
10-12 |
10-12 |
10-12 |
10-12 |
10-12 |
10-12 |
|
Air Consumption |
m³/min |
3-5 |
3-5 |
3-5 |
3-5 |
3-5 |
3-5 |
|
Cooling Water Pressure |
Mpa |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
|
Cooling Water Consumption |
L/min |
50-80 |
50-80 |
50-80 |
50-80 |
50-80 |
50-80 |
