Specifications
Ceramic silvery metalizing Machine
1. Special for ceramic to get gold and silver color.
2. Low cost, large output, easy operation
Ceramic silvery metalizing Machine is an ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is intergrating cold cathode arc discharge self
Sustained light unite pulse technique and magnetron sputtering technology, thinning the particles
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment
This machine is extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about ceramics, golf, hotel product, sanitary ware, luminaires, optical frame, hardware, etc.
Mode
Dimension
|
LH-1215
|
LH-1618
|
LH-1818
|
1200*1500mm
|
1600*1800mm
|
1800*1800mm
|
Coating mode and main confirguration
|
Fourteen multi-arc targets
|
Twenty multi-arc targets
|
Twenty four multi-arc targets
|
Power source
|
Electric-arc power, Filament power,
|
Process gas control
|
Mass flowmeter + Electromagnetic ceramic valve
|
Vacuum chamber structure
|
Vertical side opening door, pump system postposition, double water cooling
|
Vacuum system
|
Molecule pump +Roots pump +Mechanical pump(5.0*10 -5 Pa)
Diffusion pump +Roots pump +Mechanical pump(5.0*10 -4 Pa)
|
Workpiece baking temperature
|
Normal temperature to 350 centi-degree PID control, radiation heating.
|
Workpiece motion mode
|
Public rotation Frequency control: 0-20 rotation per minute
|
Measure mode
|
Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa
|
Control mode
|
Manual/Automatic/PC/PLC + HMI/PC four choice of control mode
|
Remark
|
We can design the dimension of the equipment according to customers special technique requirement.
|
