Titanium Nitride ceramic tiles golden color PVD coating machine/PVD coating equipment
The Titanium Nitride ceramic tiles golden color PVD coating machine/PVD coating equipment is suitable for coating all ceramic,porcelain,glass mosaic,mosaic tiles,also suitable for ceramic tablware and other metal products.
This is an ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate , great ionization rate, big ion energy,easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is integrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.
For more information,pls contact with : Sophia
Mobile:86 13600282018
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper , and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment.
This machine is extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about ceramics, glass, car parts, golf, watches making, hotel product, sanitary ware, luminaires, optical frame, hardware, etc .
Wall tiles PVD coating machine:
Technical parameter:
Mode
Dimension |
LH-800 |
LH-1250 |
LH-1416 |
LH-1618 |
800*1000mm |
1250*1500mm |
1400*1600mm |
1600*1800mm |
Coating mode and main confirguration |
8 multi-arc targets |
12 multi-arc targets |
14 multi-arc targets |
20 multi-arc targets |
Power source |
Electric-arc power, Filament power, Pulsed bias power supply |
Process gas control |
Mass flowmeter + Electromagnetic ceramic valve |
Vacuum chamber structure |
Vertical side opening door, pump system postposition, double water cooling |
Vacuum system |
Molecule pump +Roots pump +Mechanical pump(5.0*10-5Pa)
Diffusion pump +Roots pump +Mechanical pump(5.0*10-4Pa) |
Workpiece motion mode |
Public rotation Frequency control: 0-20 rotation per minute |
Measure mode |
Number display composite vacuum gauge: from atmosphere to 1.0*10-5Pa |
Control mode |
Manual/Automatic/PC/PLC + HMI/PC four choice of control mode |
Remark |
We can design the dimension of the equipment according to customer's special technique requirement. |
We can design the dimension of the vacuum chamber according to your requirements. We can also design and configure the vacuum unit and electric controlling system according to your requirement.
The coating experts of your own company:Full set solution for the coating production
HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; combine the full set production technics to meet your requirements, to ensure high efficiency of production.
We developed a complete after-sales system and effective service measures. Company now owns a professional after-sales service team with more than ten experienced engineers.
ISO 9001 standard to ensure the quality can meet the customer's requirements.
