Dull /Matt /Bright gold or silver plating machine/Decorative gold plating equipment
This machine integrates three technology of DC magnetron sputtering, middle frequency sputtering and electric arc ion evaporation, combining the linear ionize source and pulse bias coating to thin the deposition particles.
Applied industry: The equipment is widely used in IPG clocks, IPS watches and clocks, guns IP, mobile phone shell, hardware, sanitary ware, cutters, anti-friction tools, dies and mould, etc. It can coat TiN, TiCN, CrN, TiALN, TiNbu, TiCrN, ZrN, and various kinds of diamonds film (DLC).
It's also suitable for the other metal products coating, even can coat on glass, crystal, ceramic substrate etc. This model is also common used for the metal mobile phone shell coating, jewelries coating, golf head coating, electronic parts coating etc.
This machine can get the color like: Silver, Gold, Rose Gold, Coffee, Black, Gun Black, Blue, Purple, Rainbow color etc.
Standard size (chamber size): Diameter 1100mm*Hight 1000mm, Diameter 1350mm*Hight 1200mm.
Contact: Lillian Yang
Mobile: 0086-13825720037
Please send us your detailed requirements. We will provide the best solution for you!
Technical parameters:
Mode
Dimension | JTL-900 | JTL-1100 | JTL-1300 | JTL-1600 |
Φ9001000mm | Φ11001000mm | Φ13001200 mm | Φ16001200 mm |
Coating mode and main confirguration | 3 electric-arc+2 pairs of plane rectangular cathode | 6 electric-arc+2 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 5 electric-arc+4 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 6 electric-arc+8 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
Application | metal decorative coating |
Film Types | Metal films,Dielectric films,Compound films,Reaction films,Muti-layer function films |
Power source | Electric arc power supply,DC magnetron power supply,MF magnetron power supply.Pulse bias voltage power supply.ion source power supply. |
Process gas control | Quality flowmeter + electromagnetism ceramic valve |
Vacuum chamber structure | Vertical single(side) door, pump system postposition, double water-cooling |
Vacuum system | Molecule pump(diffusion pump)+Roots pump +Mechanical pump (8.0*10 -4 Pa) |
Pumping speed | Pumping time less than 15 minutes ,from atmospheric pressure to 310 -3 Pa |
Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
Control mode | Full automation control system PC+PLC/PC+HMI |
Remark | We can design the dimension of the equipment according to customers special technique requirement. |
DongGuan HuiCheng Vacuum Technology Co., Ltd is a high-tech enterprise specialized in the R&D, Production and Marketing of various kinds of the vacuum equipments. Our company aggregates many excellent technicians in the vacuum industry, including engineers with the senior and middle technique titles. We also invite the senior experts and experienced technicians to be responsible for the development and design of the new products, insure the high technology and quality of the vacuum equipment. Our products are popular with both the domestic and overseas clients, and have a high reputation in the vacuum industry.
Our company is dedicated to the R&D of the series of the vacuum coating machine. We have been designed various coating technics projects according to different requirements successfully, especially in the fields of mobile(computer) shell, electronical appliance, metal, auto parts and high-tech industries, etc. Particularly we designed the special wheels coating machine for the VIP enterprise in Zhejiang Province in 2007, bringing great benifits for the client, making prominent contribution to the environment protection and generating extremely positive social effectiveness. It is high appreciated by the government and craft brother. Therefor this project is listed to the item of the Nation Star Project. Our main products also include slide valve vacuum pump, Roots vacuum pump, water ring vacuum pump, rotary-vane vacuum pump, various vacuum units and different vacuum heating energy equipments, etc.
