Jiangsu Qianyili Intelligent Technology Co., LTD is a leading factory in producing high precision vertical special plastic machine industry with years. Our company owes completely imported machining equipments. Our team is always keeping improving. We are dedicated to provide advanced, professional high precision plastic injection machines.
Our flagship product is the thermosetting series machine. BMC/DMC/SMC is the main raw material.
The advantages of special plastic machine for BMC/DMC/SMC are as follows:
A. Improve the production efficiency. We have realized the several-injection clamping systems.
B. Save raw materials, beautiful appearance and environment protection.
C. No damage to glass fiber structure and guarantee the intensity of the product. Our machine can manufacture the products which contain high content glass fiber.
D. Increase the quality of the product and ensure stability yield.
E. Clear material easily and save the time.
F. Reduce the labor intensity and the production costs.
Broad application ranges of BMC/DMC/SMC:
A Auto industry
1 Lamp reflector
2 Large parts of hood, rear doors, electric heating box, engine hood, horn box, big lamp shell and branch electric head etc.
B Precision parts
Circuit breaker shell without fuses. Motorshell, loudspeaker box, cassette and video parts, copying machine, faxing machine, measuring apparatuses etc.
C Electric parts
1. High-voltage socker shell of TV parts, flyback transformer, wiring board, channel selection handle, eight-pin plug, coil bobbin and discharge etc.
2. Wiring parts like a breaker, apower distribution board, a gate switching board, a fuse box and a terminal box etc.
3. High-voltage parts, a vacuum circuit breaker shell, a baffle, an insulator and an insulating board etc.
4. Other circuit breaker bases, a micro switch and cail frame etc.
D Coil encapsulation parts
E Daily products like electriciron shells etc.
Our vertical injection molding machine suits for insert parts, precise product and twice forming parts.
Meanwhile, our company also offers professional and thoughtful service, such as a full range of technical training (planning, installation, technology, operations, etc. ). 2, in the one year warranty period, providing the machine case investigation services, machine maintenance, maintenance and debugging. 3, we received the Advisory, will be the first time to get a professional answer.
Ice, such as a full range of technical training (planning, installation, technology, operations, etc. ). 2, in the one year warranty period, providing the machine case investigation services, machine maintenance, maintenance and debugging. 3, we received the Advisory, will be the first time to get a professional answer.
|
XRT-2100B-2R |
|
Injection Unit |
Screw Diameter |
mm |
Φ50 |
Φ55 |
Φ60 |
|
Injection pressure |
Kg/cm 2 |
3348 |
2767 |
2326 |
|
Theoretical Shot Volume |
Cm 3 |
431 |
522 |
622 |
|
Shot Weight |
g/oz |
397/14 |
480/16.9 |
572/20 |
|
Injection Rate |
Cm 3 /sec |
137 |
166 |
198 |
|
Screw Rotational Speed |
rpm |
4-400 |
|
Clamping System |
Clamping Force |
ton |
210 |
|
Top Platen Size |
mm |
1735*610 |
|
Rotary Table Diameter |
mm |
1400 |
|
Mold Dimenson |
mm |
500*500/700*400 |
|
Min Mold Height |
mm |
350/450 |
|
Opening Stroke |
mm |
450 |
|
Max.Open Pitch |
mm |
800/900 |
|
Ejector Force |
T |
8.9 |
|
Ejector Stroke |
mm |
125 |
|
Others |
Pump Motor Power |
HP(kw) |
30(22) |
|
Hydraulic System Pressure |
Kw/cm 2 |
140 |
|
Heating Power |
kw |
16 |
|
Total Wattage |
kw |
38 |
|
Oil Tank Capacity |
L |
670 |
|
Machine Weight |
T |
13.7 |
|
Size(L×W×H) |
m |
3.2*2.1*5.7 |
Our factory supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
