Power:
380V
Warranty:
1 Year
Popularity:
Hot/on Sales
Operation:
Button Control
High Speed:
2500m/Min
Brand:
Hxe New
Inverter Control:
Dual Inverter Control
Type:
LT Water Tank Type Metal Drawing Machine
Usage:
Rope Wire
Max.Inlet Wire Dia.:
0.6mm-1.2mm
Outlet Diameter:
0.08mm-0.5mm
Max. Number Of Block:
24
Product Description
HXE-24DW Copper wire drawing machine
Inlet diameter
0.6mm-1.2mm
Outlet diameter
0.08mm-0.5mm
Speed
2500m/min
Dies
24
Slip ratio of machine
13%
Slip ratio of fix speed capstan
8%
Capstan
Ceramic plasma
Capstan size
242mm
Fix speed capstan siez
207mm
Frame
Iron cast
Main motor
15KW
Spool motor
3.7KW
Revise system
Synchronous control spool
Inverter control
Dual inverter control
Transmission type
Flat belt
Pay-off method
Over-head
traversing unit
Flat belt+synchronous control
Tension control
Weight balance by swing arm
Lubracation type
Spray type
Bobbin size
300mm
Spoooler capacity
50-60kg
Bobbin loading
Shaft type
Power source
380V
Brake
Pneumatic brake
Don't hesitake to cantact me if you want to but 24DW copper wire drawing machine.I will reply as soon as possible.
