Hxe-24dt Copper Wire Drawing Machine with Annealer
Price: |
Negotiable/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T |
Prod Model: |
HXE-24DT |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Warranty: |
1 Year |
Color: |
Bule/Customized |
Size: |
2100*1600*1700 |
Popularity: |
Hot/on Sales |
Dies: |
24 |
Inverter Control: |
Dual Inverter Control |
Brand Name: |
Hxe |
Operation: |
Button Control |
Usage: |
Rope Wire |
Type: |
Copper Wire Drawing Machine with Annealing |
Outlet Diameter: |
0.07mm-0.25mm |
Max.Inlet Wire Dia.: |
0.5mm-1.0mm |
Max. Number Of Block: |
24 |
Product Description
HXE-24DT Wire Drawing Machine with continuous annealer
HXE-24DT Copper wire drawing machine with online annealer is used to draw and annealer single bare copper wire from 0.5mm-1.0mm to0.07mm-0.25mm.
High speed 2000m/min
Slip ratio of machine 13%+8%
Frame Welded by steel plate
Capstan Ceramic plasma or tung sten
Capstan size 242.5mm
Fix speed size 199mm
Spooler bobbin size 300mm
Bobbin loading Shaft type
Spooler capacity 50Kg
Annealing method DC. three-section annealing
Main motor 11KW
Spool motor 3.7kw
Max anneaing current DC300A
Max annealing voltage DC50V
Annealing power 16KVA
Steam quantity 8Kg/h
Cooling water capacity 150L/min
Power source 380V 50/60HZ
Dimension 2100*1600*1700
Weight 3000Kg
