Inlet Diameter:
0.6-1.2mm
Size:
1700*1300*1850mm
Machine Weight:
2000kg
Warranty:
1year
After Service:
Engineer Available to Overseas
Popularity:
Hot/on Sales
Usage:
Wire Drawing Machine
Type:
Copper Wire Drawing Machine
Max.Inlet Wire Dia.:
0.6mm-1.2mm
Outlet Diameter:
0.1-0.32mm
Max. Number Of Block:
22
Product Description
Control system Double inverter control Dies 22 Input diameter Φ 0.6-Φ 1.2mm Output diameter Φ 0.1-Φ 0.32 mm Drawing speed MAX: 2500m/min Slip ratio of m/c 15% Slip ratio of fix speed capstan 8% Frame Ironed cast Main motor 11KW Take up motor 3.7KW Cone diamete r Φ 242mm Fix speed cone diameter Φ 206mm Spooler bobbin size MAX. Φ 380 Pay-off method Over-head Traversing unit Flat belt+synchronous motor Take up type Shaft type Transmission type By flat belts Detecting dievice Weight balance by swimming arm Tension control Weight balance type Loading capacity 50-60KG Lubrication type Spray type Brake Magnetic brake Lubrication type for bearing Without oil Power source 380V50/60Hz Lubrication oil capacity 40L/min Machine dimesion 1800*1300*1900 Machine weight 2500KG HXE-24DS FINE WIRE DRAWING MACHINE.
Suzhou Hengxie Machinery Co., Ltd. Locates in Yinghu Industrial Zone, Wangting town, Suzhou Hli-New District, near to G312 with a conveninet transportation and nice environment. It is a professional company which specializes in electronic cable, electromagnetic cable, electrical wire eat. It is at a leading position in this line because of the topping managing talent and advanced technics.
Hengxie has invested RMB ten Millons to introduce the Germany equipments and technics and developed the cable producing line by itself. This ensures the quality stable and capability superior. Hengxie has successfully set up a superior enterprise mode.
With the mange concept"Stable Quality, Mutual Development" Hengxie warmly welcome alll the friends to grant the changefor sincere cooperation and win the mutual benifit in the future.
