JD-361-Z Furan Resin-sand Automatic Core Shooting Machine
This is a kind of shooting sand core machine, you can choose coated resin sand(dry) or furan resin sand(wet), shoot the sand into the mold cavity, through the heating of the mould, it could make out the sand mould or the shell mould soonest.
Device: PLC Control
Operation: Driven by air pressure
Operating functions: Manual, senmi-auto, full-auto(with conveyer belt)
Two optional sand state: Coated resin sand(dry). Furan resin-sand(wet)
Electric heating: Automatic thermostat(dynamic mode, static mode can be an independent temperature control)
Clamping stroke: 300mm
Top lock stroke: 30mm(dynamic mold is in mechanical type, static mould is in penumatic type)
Maximum center distance of abrasive perforating: 320mm
Working pressure: 0.5-0.7mpa
Theoretic time for full-round operation: 30-60 seconds
Theoretic maximum quality of sand core
Dimensions(L*W*H): 2700mm*1280mm*2000mm
| JD-361-Z Automatic Core Shooting Machine |
| Device | PLC Control |
| Operation | Driven by air pressure |
| Operating functions | Manual, senmi-auto, full-auto(with conveyer belt) |
| Two optional sand state | Coated resin sand(dry). furan resin-sand(wet) |
| Electric heating | Automatic thermostat(dynamic mode, static mode can be an independent temperature control) |
| Clamping stroke | 300mm |
| Top lock stroke | 30mm(dynamic mold is in mechanical type, static mould is in penumatic type) |
| Maximum center distance of abrasive perforating | 320mm |
| Working pressure | 0.5-0.7mpa |
| Theoretic time for full-round operation | 30-60 seconds |
| Theoretic maximum quality of sand core | 400kgs |
| Dimensions(L*W*H) | 2700mm*1280mm*2000mm |
"Jingda Machinery" is the brand of Quanzhou Jinglong Machinery Company. We are a complete sets of sanitary plumbing equipments manufacture specially in technical process guidance, mold designing, on-site staff training services.
Main products: Gravity Casting Machine, Double Automatic Core Shooting Machine, Vertical Core Shooting Machine, Sand Mixing Machine, Biaxial Composite Machine, Low Pressure Casting Machine, Zinc Alloy Casting Machine, Pneumatic Clamps, Surface Lapping Machine etc.
We offer free professional technician training service to help technicians in well mastering the equipment operation and achieving the expectation.
